Dahua Unit VTO6221E-P User Manual

Household Setting 23
Add IPC Figure 5-14
Configure the parameters, and for the detailed description, see Table 5-4. Step 3
Table 5-4 Add IPC configuration
Parameter
Description
IPC Name
Enter the name of the device you need.
IP Addr.
The IP address of the device.
Username
The user name and password for the web interface of the
device.
Password
Port No.
Keep default value.
Protocol
Select from Local or Onvif.
Stream
Select from Main or Extra1, and the main stream has better
image quality, but also costs more bandwidth.
Channel
Define a channel for the device.
Device Type
Select from IPC, NVR, HCVR, and XVR as needed.
Click Save, and then the added device is displayed. Click to modify, and click Step 4
to delete.
You can also click Export Config to export the current devices to the local PC, or click
Import Config to import the existed configuration.
Status 5.5
You can view the working state and IP address of all the connected devices.
Log in the web interface of the SIP server, and then select Household Setting > Status.
The Status interface is displayed. See Figure 5-15.
