Dahua VTO2111D-WP User Manual

9
Figure 5-9
Note:
Parameters with * are mandatory.
Parameter
Note
Family
Name
Set username and nick name of VTH.
First Name
Nick Name
VTH Short
No.
Known as VTH room no.
Note:
VTH short no. is composed of 4 digits of number. The first two digits have
range of 01~99. The last two digits have range of 01~16.
IP Address VTH IP address.
Chart 5-6
Step 4. Click .
System displays interface when VTH is added. See Figure 5-10.
Figure 5-10
5.2.3.2 Modify VTH
 Click
, in pop-up modification page modify VTH info.
1. When you modify digital VTH, you can only modify name and nickname.
2. When you modify analog VTH, you can only modify name, nickname, distributor
address and distributor port.
 Click
, delete digital VTH.
5.2.3.3 View Card Info
Card authorization is in Ch 5.2.1.3.
Click
to view all authorized card under the VTH. See Chart 5-7.
