SQLC-214-097
47
(1) 111 to 116 Display combination setting 【All models】
● 3-phase 3-wire (Voltage, current input) (
33
)(
34
)
№ Pattern № Main monitor
Sub-monitor
(Left)
Sub-monitor
(Center)
Sub-monitor
(Right)
Bar graph
1 Pattern 1 A(V) V(UV) W Wh A(V)
2 Pattern 2 A(V) V(UV) W cosφ A(V)
3 Pattern 3 A(V) V(UV) W Hz A(V)
4 Pattern 4 DA(V) A(V) V(UV) W DA(V)
5 Pattern 5 DA(V) A(V) V(UV) Wh DA(V)
6 Pattern 6 DA(V) V(UV) W cosφ DA(V)
7 Pattern 7 W V(UV) A(V) Wh W
8 Pattern 8 W V(UV) A(V) cosφ W
9 Pattern 9 W V(UV) A(V) Hz W
10 Pattern 10 DW V(UV) W Wh DW
11 Pattern 11 DW V(UV) A(V) cosφ DW
12 Pattern 12 A(V) cosφ W Wh A(V)
13 Pattern 13 A(V) var W Wh A(V)
14 Pattern 14 W cosφ var Wh W
15 Pattern 15 A(V) A(U) A(W) Wh A(V)
16 Pattern 16 V(UV) V(VW) V(WU) Hz V(UV)
17 Pattern 17 A(U) Io/Igr (
35
) V(UV) W A(U)
18 Pattern 18 A(U) Io/Igr (
35
) V(UV) Wh A(U)
Note(
33
) Voltage input is pattern 16 only.
Note(
34
) Current input is pattern 15 only. (However, sub-monitor (right) is displayed blank.)
Note(
35
) Io/Igr is only with leakage measurement.
● Displays set factor (3-phase 3-wire)
Main monitor
V(UV)，V(VW)，V(WU)，A(U)，A(V)，A(W)，DA(U)，DA(V)，DA(W)，W，DW，var，cosφ，Hz，Io/Igr，
Wh，-Wh，varh(LAG)，varh(LEAD)，-varh(LAG)，-varh(LEAD)，Distortion factor(A,V)
Sub-monitor
(Left)
V(UV)，V(VW)，V(WU)，A(U)，A(V)，A(W)，W，var，cosφ，Io/Igr
Sub-monitor
(Center)
V(UV)，V(VW)，V(WU)，A(U)，A(V)，A(W)，DA(U)，DA(V)，DA(W)，W，DW，var，
varh(LAG)，varh(LEAD)，-varh(LAG)，-varh(LEAD)，Harmonic 5th conversion content(A,V)，
Harmonic nth content(A,V)
Sub-monitor
(Right)
V(UV)，V(VW)，V(WU)，A(U)，A(V)，A(W)，DA(U)，DA(V)，DA(W)，W，DW，cosφ，Hz，
Wh，-Wh，Fundamental-wave effective value(A,V)，Harmonic 5th conversion effective value(A,V)，
Harmonic nth effective value(A,V)
Bar graph
V(UV)，V(VW)，V(WU)，A(U)，A(V)，A(W)，DA(U)，DA(V)，DA(W)，W，DW，var，cosφ，Hz，Io/Igr，
Distortion factor(A,V)，Harmonic 5th conversion content(A,V)，Harmonic nth content(A,V)，
Fundamental-wave effective value(A,V)，Harmonic 5th conversion effective value(A,V)，
Harmonic nth effective value(A,V)
● Phase (line) change (3-phase 3-wire) ● Measurement factor change (3-phase 3-wire, Measurement display mode)
(
36
)
V(UV) V(VW) V(WU)
A(V) A(W) A(U)
● Measurement factor change (3-phase 3-wire, Harmonic measurement display mode）
Main monitor ：Distortion factor (Fixation)
Sub-monitor (Left) ：Harmonic order ｎ 5th conversion 1 3 4 5 7 9 11 13 15
Sub-monitor (Center)：Harmonic nth content (Fixation)
Sub-monitor (Right) ：Harmonic nth effective value (Fixation)
Note(
36
) Press DISPLAY , Voltage and
current are replaced at the
same time.
V(UV) V(VW) V(WU) A(U) A(V) A(W) DA(U)
DA(V) DA(W) W DW var cosφ Hz
Io/Igr Wh -Wh varh(LAG) varh(LEAD)
-varh(LAG) -varh(LEAD) Nothing
