5.2 Setting table
A setting item changes by the specification of a product, or the existence of an option.
(1) Important setting
Each parenthesized number shows a setting number and this number is displayed on the setting screen.
Items Setting and operation procedures Page
Set the measurement
range of voltmeter
(211)
Press
SET and RESET/SHIFT together for longer than 3 seconds
(211)
Select a measurement range by ＋ and －
Press SET
Selected measurement range is entered
Press DISPLAY Returns to display mode.
58-60
Set the measurement
range of ammeter
(212)
Press
SET and RESET/SHIFT together for longer than 3 seconds Press RESET/SHIFT
(211) (212)
Select a measuring range by ＋ and －
Press SET
Selected measuring range is entered
Press DISPLAY Returns to display mode.
58-60
Set the display
combination
(111)
Press
SET for longer than 3 seconds Select the display combination by ＋ and －
(111)
Press
SET Selected display combination is entered Press DISPLAY
Returns to display mode.
47-51
Set the output
factor of analog
output 1 (AO1).
(221A)
Press
SET and RESET/SHIFT together for longer than 3 seconds Press MODE
(211) (221A)
Select an output factor by ＋ and －
Press SET
Selected output factor is entered
Press DISPLAY Returns to display mode.
61,62
Set the output
factor of analog
output 2 (AO2).
(222A)
Press
SET and RESET/SHIFT together for longer than 3 seconds Press MODE
(211) (221A)
Press
RESET/SHIFT Select an output factor by ＋ and － Press SET
(222A)
Selected output factor is entered
Press DISPLAY Returns to display mode.
61,62
Set the output
factor of analog
output 3 (AO3).
(223A)
Press
SET and RESET/SHIFT together for longer than 3 seconds Press MODE
(211) (221A)
Press
RESET/SHIFT Press RESET/SHIFT Select an output factor by ＋ and －
(222A) (223A)
Press
SET Selected output factor is entered Press DISPLAY Returns to
display mode.
61,62
Set the output
factor of analog
output 4 (AO4).
(224A)
Press
SET and RESET/SHIFT together for longer than 3 seconds Press MODE
(211) (221A)
Press
RESET/SHIFT Press RESET/SHIFT Press RESET/SHIFT
(222A) (223A) (224A)
Select an output factor by ＋ and －
Press SET
Selected output factor is entered
Press DISPLAY Returns to display mode.
61,62
Set the output
factor of pulse
output 1 (PO1).
(241P)
Press
SET and RESET/SHIFT together for longer than 3 seconds Press MODE
(211) (221A)
Press
MODE Select an output factor by ＋ and － Press SET
(241P)
Selected output factor is entered
Press DISPLAY Returns to display mode.
62
Set the output
factor of pulse
output 2 (PO2).
(243P)
Press
SET and RESET/SHIFT together for longer than 3 seconds Press MODE
(211) (221A)
Press
MODE Press RESET/SHIFT Press RESET/SHIFT
(241P) (242P) (243P)
Select an output factor by ＋ and －
Press SET
Selected output factor is entered
Press DISPLAY Returns to display mode.
62
