Daiichi Electronics SQLC-110L - 5 Setting; Function Table

SQLC-214-097
32
5. Setting
5.1 Function table
This product has each function setting with a front switch.
<Caution> In case the input circuit is not designated at the case of an order, it is shipping in the default value
of 3-phase 3-wire.
Setting mode 1. Function table (1)
Setting
No.
Function Functional description
Current
input
Voltage
input
Default setting
Important
setting
Page
111 Display pattern
Set the display combination pattern
of the digital 4 displays and bar
graph display.
○ ○ Pattern 1 ○ 47-51
112 Main monitor
Set the display factor of digital main
monitor.
○ ○
3φ3W A(V)
○ 47-51 1φ3W A(U)
1φ2W A
113
Sub-monitor
(Left)
Set the display factor of digital
sub-monitor (left).
○ ○
3φ3W V(UV)
○ 47-51 1φ3W V(UN)
1φ2W V
114
Sub-monitor
(Center)
Set the display factor of digital
sub-monitor (center).
○ ○ W ○ 47-51
115
Sub-monitor
(Right)
Set the display factor of digital
sub-monitor (right).
○ ○ Wh ○ 47-51
116 Bar graph Set the display factor of bar graph. ○ ○
3φ3W A(V)
○ 47-51 1φ3W A(U)
1φ2W A
121AL
(
23
)
Alarm 1 factor Set the output factor of alarm 1. ○ ○ DA ○ 52
122AL
(
23
)
Alarm 1 return
method
Set the output action at the case
of reset of alarm 1.
○ ○ Automatic reset 52
123AL
(
23
)
Alarm 1 mask time
(Contact delay
time)
Set the contact delay time of alarm 1. ○ ○ 0 second 52
124AL
(
23
)
Alarm 1 test Output test of alarm 1 is performed. ○ ○ － 52
125AL
(
23
)
Alarm 2 factor Set the output factor of alarm 2. ○ ○ DA ○ 52
126AL
(
23
)
Alarm 2 return
method
Set the output action at the case
of reset of alarm 2.
○ ○ Automatic reset 52
127AL
(
23
)
Alarm 2 mask time
(Contact delay
time)
Set the contact delay time of alarm 2. ○ ○ 0 second 52
128AL
(
23
)
Alarm 2 test Output test of alarm 2 is performed. ○ ○ － 52
131H
Demand current
upper limit
Sets the high-alarm value of demand
current.
○
80
%
(Full scale＝
100
% )
53,54
132
Demand current time
interval
Set time interval of demand current. ○ 0 second ○ 53,54
133H
Demand active power
upper limit
Set the high-alarm value of demand
active power.
OFF (No operation) 53,54
Note(
23
) A setting item is not displayed in case there is no corresponding option.
When changing the input circuit setting, please be sure to perform a setup from an input circuit setting in
the setting mode 3. After changing the other setting, when the input circuit setting is changed the set value
returns to default value (default value of a changed input circuit).
< Caution >
