Setting mode 1. Function table (2)
Setting
No.
Function Functional description
Current
input
Voltage
input
Default setting
Important
setting
Page
134
Demand active power
time interval
Set the time interval of demand active
power.
0 second ○ 53,54
135
Demand active power
operating method
Set the operating method of demand
active power.
Operating system
according with
bimetallic type.
○ 53,54
136
Power-factor
operating method
Set the operating method of
power-factor measurement.
Instant
measurement
53,54
141H
Current
distortion-factor
upper limit
Set the high-alarm value of current
distortion factor.
○ OFF (No operation) 54,55
142H
Current 5th
conversion content
upper limit
Set the high-alarm value of current 5th
conversion content.
○ OFF (No operation) 54,55
143
Current n-th
content factor
Set the order of n-th current content. ○ 5th 54,55
144H
Current n-th
content upper limit
Set the high-alarm value of current
n-th content.
○ OFF (No operation) 54,55
145H
Voltage
distortion-factor
upper limit
Set this high-alarm value of voltage
distortion factor.
○ OFF (No operation) 54,55
146H
Voltage 5th
conversion content
upper limit
Set the high-alarm value of voltage 5th
conversion content.
○ OFF (No operation) 54,55
147
Voltage n-th
content factor
Set the order of n-th voltage content. ○ 5th 54,55
148H
Voltage n-th
content upper limit
Set the high-alarm value of voltage
n-th content.
○ OFF (No operation) 54,55
149
5th conversion
detection
characteristics
Set the detection characteristic of
5th conversion content.
○ ○
Inverse-time-dela
y mode
54,55
14A
Average value time
interval
Set the average value detection time
interval of harmonic.
○ ○ 0 minute 54,55
151H
Instant measurement
voltage upper limit
Set the high-alarm value of instant
voltage.
○ OFF (No operation) 55
152L
Instant measurement
voltage lower limit
Set the low-alarm value of instant
voltage.
○ OFF (No operation) 55
161
(
24
)
Leakage detection
rated sensitivity
current value
Set the rated sensitivity current
value of current leakage.
○ ○ 0.1A 56
162
(
24
)(
25
)
Leakage detection
factor change
Set the factor of the current
leakage that performs leakage
detection.
○ ○ Io 56
163
(
24
)
Leakage
detect-circuitry
change
Set the circuit configuration at the
time that 3-phase 3-wire performs
leakage detection.
○ ○ One phase earth 56
164
(
24
)
Selection of ZCT
used
Sets the ZCT used by current-leakage
measurement.
○ ○ TYPE 0 56
171 Backlight action Set the ON/OFF of backlight. ○ ○ AUTO OFF 57
172
Backlight
brightness
Set the brightness of backlight. ○ ○ 3（Middle） 57
Note(
24
) A setting item is not displayed in case there is no corresponding option.
Note(
25
) Current input product are only Io detection. Igr detection cannot be performed.
