Daiichi Electronics SQLC-110L - Setting Mode 2 Functions

SQLC-214-097
34
Setting mode 2. Function table (1)
Setting
No.
Function Functional description
Current
input
Voltage
input
Default setting
Important
setting
Page
211 Voltage range
Set the voltage-measurement range
(VT ratio).
○
3φ3W 6600V (
27
)
○
58-60
1φ3W 110.0V
1φ2W 3300V (
27
)
212 Current range
Set the current-measurement range
(CT ratio).
○
3φ3W 100.0A
○
58-60
1φ3W 500A
1φ2W 50.0A
213
Current display
peculiar
sensitivity
Set the full scale of current meter. ○
3φ3W 100.0A
58-60
1φ3W 500A
1φ2W 50.0A
214
Active power
polarity
Set the swing display of active power
meter.
One-side swing
58-60
215 Active power range
Set the full scale of active power
meter.
3φ3W 1200kW (
28
)
58-60
1φ3W 100.0kW
1φ2W 150.0kW (
28
)
216
Reactive power
range
Set the full scale of reactive power
meter.
3φ3W 600kvar
(
28
)
58-60
1φ3W 50.0kvar
1φ2W 75.0kvar(
28
)
217 Power-factor range
Set the full scale of power-factor
meter. And, set this output range
of analog output.
0.5‐1‐0.5
58-60
218 Frequency range
Set the full scale of frequency meter.
And, set this output range of analog
output.
○ 45‐65Hz
58-60
221A
(
26
)
AO1 output factor
Set the output factor of AO1 (analog
output 1).
○ ○
3φ3W A(V)
○ 61,62
1φ3W A(U)
1φ2W A
222A
(
26
)
AO2 output factor
Set the output factor of AO2 (analog
output 2).
○ ○
3φ3W V(UV)
○ 61,62
1φ3W V(UN)
1φ2W V
223A
(
26
)
AO3 output factor
Set the output factor of AO3 (analog
output 3).
○ ○ W ○ 61,62
224A
(
26
)
AO4 output factor
Set the output factor of AO4 (analog
output 4).
○ ○ cosφ ○ 61,62
225A
(
26
)
Current output
peculiar
sensitivity
Set the analog output sensitivity
(％ of output for input) of current.
○ 100.0％ 61,62
226A
(
26
)
Active power-output
peculiar
sensitivity
Set the analog output sensitivity
(％ of output for input) of active
power.
100.0％ 61,62
227A
(
26
)
Reactive power
output peculiar
sensitivity
Set the analog output sensitivity
(％ of output for input) of reactive
power.
50.0％ 61,62
228A
(
26
)
Low input cut
Set the function which makes a lower
limit the output at the case of a
minute input (adequate to 0.5％ or
less) in analog output.
○ ○ OFF (No operation) 61,62
Note(
26
) A setting item is not displayed in case there is no corresponding option.
Note(
27
) In 220V input, it becomes "220V".
Note(
28
) In 220V input, It becomes "40.0kW" and "20.00kvar" (3φ3W).
In 220V input, It becomes "10.00kW" and "5.00kvar" (1φ2W).
