Daiichi Electronics SQLC-110L - Page 36

SQLC-214-097
35
Setting mode 2. Function table (2)
Setting
No.
Function Functional description
Current
input
Voltage
input
Default setting
Important
setting
Page
241P
(
29
)
PO1 factor
Set the output factor of PO1 (pulse
output 1).
Wh ○ 62
242P
(
29
)(
30
)
PO1 pulse unit
Set the output pulse unit of PO1
(pulse output 1).
3φ3W 10kWh/p
62
1φ3W
1φ2W
1kWh/p
243P
(
29
)
PO2 factor
Set the output factor of PO2 (pulse
output 2).
Wh ○ 62
244P
(
29
)(
30
)
PO2 pulse unit
Set the output pulse unit of PO2
(pulse output 2).
3φ3W 10kWh/p
62
1φ3W
1φ2W
1kWh/p
251
(
29
)
External operation
input 1 function
Set the function of the external
operation input 1.
○ ○ Alarm reset ○ 63
252
(
29
)
External operation
input 2 function
Set the function of the external
operation input 2.
○ ○
Maximum / Minimum
reset
○ 63
261 Voltage ON/OFF
Set the ON/OFF of voltage measurement
display.
○ ON 64
262 Current ON/OFF
Set the ON/OFF of current measurement
display.
○ ON 64
263 Active power ON/OFF
Set the ON/OFF of active power
measurement display.
ON 64
264
Reactive power
ON/OFF
Set the ON/OFF of reactive power
measurement display.
ON 64
265 Power-factor ON/OFF
Set the ON/OFF of power-factor
measurement display.
ON 64
266 Frequency ON/OFF
Set the ON/OFF of frequency
measurement display.
○ ON 64
267
Power-receiving
watt-hour ON/OFF
Set the ON/OFF of power-receiving
watt-hour measurement display.
ON 64
268
Power transmission
var-hour ON/OFF
Set the ON/OFF of power transmission
var-hour measurement display.
ON 64
269
Power-receiving
var-hour (LAG,LEAD)
ON/OFF
Set the ON/OFF of power-receiving
var-hour (LAG,LEAD) measurement
display.
ON 64
26A
Power transmission
var-hour (LAG,LEAD)
ON/OFF
Set the ON/OFF of power transmission
var-hour (LAG,LEAD) measurement
display.
ON 64
26B
Harmonic current
ON/OFF
Set the ON/OFF of harmonic current
measurement display.
○ ON 64
26C
Harmonic voltage
ON/OFF
Set the ON/OFF of harmonic voltage
measurement display.
○ ON 64
26D
(
29
)
Current leakage
ON/OFF
Set the ON/OFF of current-leakage
measurement display.
○ ○ ON 64
271
set value
initialization
All set values are initialized.
(Return to default setting)
○ ○ － 64
272 Watt-hour reset
Integrated value is cleared by package
about each electric energy.
－ 64
Note(
29
) A setting item is not displayed in case there is no corresponding option.
Note(
30
) In 220V input, it becomes "0.1kWh/p". (3φ3W、1φ2W)
