Daiichi Electronics SQLC-110L - Setting Mode 3 Functions

SQLC-214-097
36
Setting mode 3. Function table
Setting
No.
Function Functional description
Current
input
Voltage
input
Default setting
Important
setting
Page
311
Input circuit phase
line change
Set the input circuit or phase line. ○ ○
3φ3W 3φ3W
○ 66 1φ3W
1φ3W
(U-N-W)
1φ2W 1φ2W
312 Input voltage
Set the input voltage or phase-voltage
full scale.
○
3φ3W 110V
○ 66 1φ3W 300V
1φ2W 110V
321
Measurement dead
band
Set the dead band of measurement
display.
○ ○ 0.0％ 67
322
Tidal current
measurement
Set the general measurement or tidal
current measurement which was
conscious of power transmission /
power receiving, in measurement of
reactive power and power-factor.
General
measurement
67
331
(
31
)(
32
)
Analog output
specification
Set the analog output specification. ○ ○
DC1‐5V or DC0‐5V
(Designation )
68
341
(
31
)
AO1 BIAS adjustment
Set the BIAS value of AO1 (Analog
output 1).
○ ○ 0.0％ 68
342
(
31
)
AO1 SPAN adjustment
Set the SPAN value of AO1 (Analog
output 1).
○ ○ 100.0％ 68
343
(
31
)
AO2 BIAS adjustment
Set the BIAS value of AO2 (Analog
output 2).
○ ○ 0.0％ 68
344
(
31
)
AO2 SPAN adjustment
Set the SPAN value of AO2 (Analog
output 2).
○ ○ 100.0％ 68
345
(
31
)
AO3 BIAS adjustment
Set the BIAS value of AO3 (Analog
output 3).
○ ○ 0.0％ 68
346
(
31
)
AO3 SPAN adjustment
Set the SPAN value of AO3 (Analog
output 3).
○ ○ 100.0％ 68
347
(
31
)
AO4 BIAS adjustment
Set the BIAS value of AO4 (Analog
output 4).
○ ○ 0.0％ 68
348
(
31
)
AO4 SPAN adjustment
Set the SPAN value of AO4 (Analog
output 4).
○ ○ 100.0％ 68
Note(
31
) A setting item is not displayed in case there is no corresponding option.
Note(
32
) A setting item is not displayed if analog output is except DC0‐5V (or DC1‐5V) specification,
And analog output insulation product does not display a setting item.
