SQLC-214-097
49
● Single-phase 2-wire (Voltage, current input) (
41
)(
42
)
№ Pattern № Main monitor
Sub-monitor
(Left)
Sub-monitor
(Center)
Sub-monitor
(Right)
Bar graph
1 Pattern 1 A V W Wh A
2 Pattern 2 A V W cosφ A
3 Pattern 3 A V W Hz A
4 Pattern 4 DA A V W DA
5 Pattern 5 DA A V Wh DA
6 Pattern 6 DA V W cosφ DA
7 Pattern 7 W V A Wh W
8 Pattern 8 W V A cosφ W
9 Pattern 9 W V A Hz W
10 Pattern 10 DW V W Wh DW
11 Pattern 11 DW V A cosφ DW
12 Pattern 12 A cosφ W Wh A
13 Pattern 13 A var W Wh A
14 Pattern 14 W cosφ var Wh W
15 Pattern 15 A － － Wh A
16 Pattern 16 V － － Hz V
17 Pattern 17 A Io/Igr (
43
) V W A
18 Pattern 18 A Io/Igr (
43
) V Wh A
Note(
41
) Voltage input is pattern 16 only.
Note(
42
) Current input is pattern 15 only. (However, sub-monitor (right) is displayed blank.)
Note(
43
) Io/Igr is only with leakage measurement.
● Displays set factor (Single-phase 2-wire)
Main monitor
V，A，DA，W，DW，var，cosφ，Hz，Io/Igr，Wh，-Wh，varh(LAG)，varh(LEAD)，-varh(LAG)，
-varh(LEAD)，Distortion factor(A,V)
Sub-monitor
(Left)
V，A，W，var，cosφ，Io/Igr
Sub-monitor
(Center)
V，A，DA，W，DW，var，varh(LAG)，varh(LEAD)，-varh(LAG)，-varh(LEAD)，
Harmonic 5th conversion content(A,V)，Harmonic nth content(A,V)
Sub-monitor
(Right)
V，A，DA，W，DW，cosφ，Hz，Wh，-Wh，Fundamental-wave effective value(A,V)，
Harmonic 5th conversion effective value(A,V)，Harmonic nth effective value(A,V)
Bar graph
V，A，DA，W，DW，var，cosφ，Hz，Io/Igr，Distortion factor(A,V)，
Harmonic 5th conversion content(A,V)，Harmonic nth content(A,V)，
Fundamental-wave effective value(A,V)，Harmonic 5th conversion effective value(A,V)，
Harmonic nth effective value(A,V)
● Measurement factor change (Single-phase 2-wire, Measurement display mode)
V A DA W DW var cosφ Hz Io/Igr Wh -Wh
varh(LAG) varh(LEAD) -varh(LAG) -varh(LEAD) Nothing
● Measurement factor change (Single-phase 2-wire, Harmonic measurement display mode）
Main monitor ：Distortion factor (Fixation)
Sub-monitor (Left) ：Harmonic order ｎ
5th conversion 1 3 4 5 7 9 11 13 15
Sub-monitor (Center)：Harmonic nth content (Fixation)
Sub-monitor (Right) ：Harmonic nth effective value (Fixation)
