(5) 261 to 26D Measurement ON/OFF setting 【All models (However, a current leakage is with leakage measurement)】
Measurement display ON/OFF setting of each measurement factor is performed.
Selection by
＋ and － , set value is updated by SET .
Default setting：ON (All measurement factors)
261
Voltage
RESET/
SHIFT
RESET/
SHIFT
RESET/
SHIFT
262
Current
263
Power
264
Reactive
power
26C
Harmonic
voltage
269
Power-receiving
reactive watt-hour
(LAG,LEAD)
26B
Harmonic
current
26A
Power transmission
reactive watt-hour
(LAG,LEAD)
265
Power-factor
268
Power
transmission
watt-hour
266
Frequency
267
Power-receiving
watt-hour
RESET/
SHIFT
RESET/
SHIFT
RESET/
SHIFT
RESET/
SHIFT
26D
Current
leakage
RESET/
SHIFT
RESET/
SHIFT
RESET/
SHIFT
RESET/
SHIFT
RESET/
SHIFT
RESET/
SHIFT
(6) 271 to 272 Initialization of watt-hour and setting value. 【All models 】
Package reset of watt-hour is performed. And, each set value is initialized (returns to default setting).
271
Setting value is
initialized.
RESET/
SHIFT
RESET/
SHIFT
272
Watt-hour reset
◆ 271 Initialization of setting value
Each set value is initialized (returns to default setting).
Pushing
SET for 3 seconds initializes all set values.
◆ 272 Watt-hour reset
Integrated value of each electric-energy display is cleared (＝0). By pushing
SET for 3 seconds, all integrated
value (Wh, -Wh, var(LAG), -var(LAG), var(LEAD), var(LEAD)) is cleared by package.
SET
3 seconds
(Before initialization)
(Initialization completion)
Initialization of setting value
Setting No.
Completion of
initializing
Setting No.
(Before clear)
(Clear completion)
Watt-hour reset
Setting No.
Wh and varh are
displayed by
turns.
Setting No.
Wh and varh are
displayed by turns.
Clear completion
After clear
completion
SET
3 seconds
Voltage ON/OFF
Setting No.
New setting
Current setting
