pressure drop daTa
www.DaikinApplied.com 41 IOM 1242-2 • PATHFINDER
®
MODEL AWV CHILLERS
Figure 57: Model EV66391414/11
Figure 58: Model EV66391616/09
Figure 59: Model EV66391717/07
0
10
20
30
40
50
0 200 400 600 800 1000 1200
PD
(ft)
Flow Rate (gpm)
Evaporator EV66391414/11
0
10
20
30
40
50
0 200 400 600 800 1000 1200 1400
PD
(ft)
Flow Rate (gpm)
Evaporator EV66391616/09
0
10
20
30
40
0 200 400 600 800 1000 1200 1400 1600 1800
PD
(ft)
Flow Rate (gpm)
Evaporator EV663917170/7
