24 Installation Manual 3P581074-2D
DGE601A52
English
A B E
DC
In case of connecting to the iTM
A
iTM
(For details on iTM, refer to “intelligent Touch Manager Installation Manual
(3P291714-1)”)
B DGE601A52
C plus ADP IF (iTM)
D plus ADP IF (DGE601A52)
E DGE601A52/DGE601A53 on which termination resistor must be enabled
(For details on DGE601A53, refer to “DGE601A53 Installation Manual (3P583694-4)”.)
