Installation Manual 3P581074-2D
DGE601A52
25English
When adding a DGE601A52 in another location
In case a DGE601A53 has been added, wire from the last SLOT.
In case a DGE601A53 has not been added, tighten the wires together.
<Schematic connection diagram of adding a DGE601A52>
A B C C B’
A B B’
Control enclosure 1
In case a DGE601A53 has been added
In case a DGE601A53 has not been added
Control enclosure 2
Control enclosure 1 Control enclosure 2
A DGE601A51/iTM
B DGE601A52
B’ Added DGE601A52
C DGE601A53
