Wired Remote Controller ESIE15-13B
12 Remote Controller
35.FAN SPEED BUTTON
This button toggles between L (Low), H (High), HH (very High), (Automatic).
36.AIRFLOW DIRECTION ADJUST BUTTON
This button enables to adjust the airflow direction.
37.AIR FILTER CLEANING TIME ICON RESET BUTTON
This button is used to reset the air filter cleaning time icon.
1.2.2 BRC1E52/53
1. Operation mode selector button
Press this button to select the operation mode of your preference.
*Available modes vary with the connecting model.
2. Fan speed control button
Press this button to select the fan speed of your preference.
*Available fan speed vary with the connecting model.
3. Menu/Enter button
Used to indicate the main menu.
Used to enter the setting item selected.
4. Up button (Be sure to press the part with the symbol )
Used to raise the set temperature.
The next items on the upper side will be highlighted.
(The highlighted items will be scrolled continuously when the button is kept pressed.)
Used to change the item selected.
5. Down button (Be sure to press the part with the symbol )
Used to lower the set temperature.
The next items on the lower side will be highlighted.
(The highlighted items will be scrolled continuously when the button is kept pressed.)
Used to change the item selected.
2. Fan speed control button
3. Menu/Enter button
8. On/Off button
10. Cancel button
9. Operation lamp
11. LCD (with backlight)
4. Up button
5. Down button
6. Right button
7. Left button
1. Operation mode
selector button
To Next Page
