Specifications SiBE01-503
6 Specifications
1. Specifications
50Hz 230V
Note:
MAX. interunit piping length: 15m
MAX. interunit height difference: 10m
Amount of additional charge of refrigerant 20g/m for piping length exceeding 7.5m(25 class), 10m(35class)
The data are based on the conditions shown in the table below.
Models
Indoor Units FTYN25DV3B FTYN35DV3B
Outdoor Units
RYN25DV3B RYN35DV3B
Cooling Heating Cooling Heating
Capacity
Rated (Min.~Max.)
kW 2.5 3 3.15 3.85
Btu/h 8,550 10,260 10,770 13,160
kcal/h 2,150 2,580 2,710 3,310
Moisture Removal L/h 1.2 — 1.9 —
Running Current (Rated) A 4.0 4.0 5.4 5.8
Power Consumption
Rated (Min.~Max.)
W 830 880 1,200 1,290
Power Factor %90969797
COP (Rated) W/W 3.01 3.41 2.63 2.98
Piping
Connections
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
18.0
φ
18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Indoor Units FTYN25DV3B FTYN35DV3B
Front Panel Color White White
Air Flow Rate
m³/min
(cfm)
H 7.5 (265) 7.8 (275) 7.5 (265) 7.8 (275)
M 6.0 (212) 6.3 (222) 6.1 (215) 6.4 (226)
L 4.6 (162) 4.8 (169) 4.9 (173) 5.2 (184)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 18 18
Speed Steps 3 Steps, Powerful, Auto 3 Steps, Powerful, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.19 0.19 0.19 0.19
Power Consumption (Rated) W 40 40 40 40
Power Factor %92929292
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 273×784×195 273×784×195
Packaged Dimensions (H×W×D) mm 260×840×330 260×840×330
Weight kg 9 9
Gross Weight kg 11 11
Operation
Sound
H/M/L dBA 39 / 33 / 27 39 / 33 / 27 39 / 34 / 29 39 / 34 / 29
Sound Power H dBA 57 57 57 57
Outdoor Units RYN25DV3B RYN35DV3B
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Rotary Type Hermetically Sealed Rotary Type
Model 5PS112DAH21 5KS150DBK21
Motor Output W 750 1,100
Refrigerant
Oil
Type FV50S FV50S
Charge L 0.35 0.43
Refrigerant
Type R410A R410A
Charge kg 0.9 1.0
Air Flow Rate
m³/min 28 25.2 28 25.2
cfm 988 890 988 890
Fan
Type Propeller Propeller
Motor Output W 23 23
Running Current (Rated) A 3.81 3.81 5.21 5.61
Power Consumption (Rated) W 790 840 1,160 1,250
Power Factor %90969797
Starting Current A 18.6 23.1
Dimensions (H×W×D) mm 560×695×265 560×695×265
Packaged Dimensions (H×W×D) mm 607×824×337 607×824×337
Weight kg 31 36
Gross Weight kg 35 40
Operation
Sound
H dBA 47 49 48 49
Sound Power H dBA 62 64 63 64
Drawing No. 3D048831 3D048830
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Heating Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
Indoor ; 20°CDB
Outdoor ; 7°CDB/6°CWB
7.5m
