SiBE01-503 Specifications
Specifications 7
50Hz 220V
Note:
MIN. interunit piping length: 3m
MAX. interunit piping length: 12m
MAX. interunit height difference: 10m
Amount of additional charge of refrigerant 20g/m for piping length exceeding 5m
The data are based on the conditions shown in the table below.
Models
Indoor Units ATY20DV2 ATY25DV2
Outdoor Units
ARY20DV2 ARY25DV2
Cooling Heating Cooling Heating
Capacity
kW 1.95 2.3 2.5 2.8
Btu/h 6,700 7,900 8,500 9,600
kcal/h 1,680 1,980 2,150 2,410
Moisture Removal L/h 0.8 — 1.2 —
Running Current A 3.6 3.2 4.0 3.6
Power Consumption W 680 600 840 770
Power Factor %86859597
COP W/W 2.87 3.83 2.98 3.64
Piping
Connections
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
18.0
φ
18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Indoor Units ATY20DV2 ATY25DV2
Front Panel Color White White
Air Flow Rate
m³/min
(cfm)
H 7.2 (254) 7.5 (265) 7.5 (265) 7.8 (275)
M 5.9 (208) 6.2 (219) 6.0 (212) 6.3 (222)
L 4.6 (162) 4.8 (169) 4.6 (162) 4.8 (169)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 18 18
Speed Steps 3 Steps, Powerful, Auto 3 Steps, Powerful, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current A 0.19 0.19 0.19 0.19
Power Consumption W 40 40 40 40
Power Factor %96969696
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 273×784×195 273×784×195
Packaged Dimensions (H×W×D) mm 260×840×330 260×840×330
Weight kg 9 9
Gross Weight kg 11 11
Operation
Sound
H/M/L dBA 38 / 33 / 27 38 / 33 / 27 39 / 33 / 27 39 / 33 / 27
Outdoor Units ARY20DV2 ARY25DV2
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Rotary Type Hermetically Sealed Rotary Type
Model 2R13C225BSA 2P16C225ANF
Motor Output W 600 750
Refrigerant
Oil
Type ATMOS M60 or SUNISO 4GDID ATMOS M60 or SUNISO 4GDID
Charge L 0.3 0.35
Refrigerant
Type R22 R22
Charge kg 0.75 0.75
Air Flow Rate
m³/min 28 25.2 28 25.2
cfm 988 890 988 890
Fan
Type Propeller Propeller
Motor Output W 23 23
Running Current A 3.41 3.01 3.81 3.41
Power Consumption W 640 560 800 730
Power Factor %85859597
Starting Current A 14 15.6
Dimensions (H×W×D) mm 560×695×265 560×695×265
Packaged Dimensions (H×W×D) mm 607×824×337 607×824×337
Weight kg 26 28
Gross Weight kg 28 31
Operation Sound dBA 46 47 46 47
Drawing No. 3D048822 3D048821
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Heating Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
Indoor ; 20°CDB
Outdoor ; 7°CDB/6°CWB
5m
