Specifications SiBE01-503
8 Specifications
50Hz 220V
Note:

MIN. interunit piping length: 3m

MAX. interunit piping length: 12m

MAX. interunit height difference: 10m

Amount of additional charge of refrigerant 20g/m for piping length exceeding 5m

The data are based on the conditions shown in the table below.
Models
Indoor Units ATY35DV2
Outdoor Units
ARY35DV2
Cooling Heating
Capacity
kW 3.3 3.8
Btu/h 11,300 13,000
kcal/h 2,840 3,270
Moisture Removal L/h 1.9 —
Running Current A 5.4 5.6
Power Consumption W 1,110 1,180
Power Factor % 93 96
COP W/W 2.97 3.22
Piping
Connections
Liquid mm
φ
6.4
Gas mm
φ
12.7
Drain mm
φ
18.0
Heat Insulation Both Liquid and Gas Pipes
Indoor Units ATY35DV2
Front Panel Color White
Air Flow Rate
m³/min
(cfm)
H 7.5 (265) 7.8 (275)
M 6.1 (215) 6.4 (226)
L 4.9 (173) 5.2 (184)
Fan
Type Cross Flow Fan
Motor Output W 18
Speed Steps 3 Steps, Powerful, Auto
Air Direction Control Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof
Running Current A 0.19 0.19
Power Consumption W 40 40
Power Factor % 96 96
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 273×784×195
Packaged Dimensions (H×W×D) mm 260×840×330
Weight kg 9
Gross Weight kg 11
Operation
Sound
H/M/L dBA 39 / 34 / 29 39 / 34 / 29
Outdoor Units ARY35DV2
Casing Color Ivory White
Compressor
Type Hermetically Sealed Rotary Type
Model 2K22C225EUE
Motor Output W 1,100
Refrigerant
Oil
Type ATMOS M60 or SUNISO 4GDID
Charge L 0.41
Refrigerant
Type R22
Charge kg 0.95
Air Flow Rate
m³/min 28 25.2
cfm 988 890
Fan
Type Propeller
Motor Output W 23
Running Current A 5.21 5.41
Power Consumption W 1,070 1,140
Power Factor % 93 96
Starting Current A 22.8
Dimensions (H×W×D) mm 560×695×265
Packaged Dimensions (H×W×D) mm 607×824×337
Weight kg 36
Gross Weight kg 40
Operation Sound dBA 47 48
Drawing No. 3D048820
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Heating Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
Indoor ; 20°CDB
Outdoor ; 7°CDB/6°CWB
5m
