3.1.2 Installation procedure
Secure the iTM plus adaptor to the control enclosure using the supplied round-head wood
screws. When done, remove the blue protective lm from the upper portion of the unit
body.
<Mounting to control enclosure>
3.2 DIN rail mounting
The iTM plus adaptor can be mounted to a 1-3/8 in. DIN rail.
<Mounting to DIN rail>
Do not use screws to secure the iTM plus adaptor onto the DIN rail.
