1 Before Installation
Before you start installing the iTM plus adaptor, complete the following checks:
• Check that the iTM plus adaptor comes with all accessories.
• Understand where the terminals and switches of the iTM plus adaptor are located.
• Make sure that an appropriate space for installing the iTM plus adaptor is available.
1.1 Checking that all accessories are included
Based on the following accessory list, check that all accessories for the iTM plus adaptor
are included. Should there be any missing or defective parts, contact your dealer.
<Accessories included with iTM plus adaptor>
A B
C
D
d-2
d-1
a-1
b-1
c-1
A (a-1) iTM plus adaptor body (1 pc.)
B (b-1) Round-head wood screw (φ3.5×16), 4 pcs.
C (c-1) Cable tie, 1 pc.
D (d-1) Installation manual (This manual), 1 pc. (d-2) Manual CD, 1 pc.
