OM 1263 • MICROTECH UNIT CONTROLLER 34 www.DaikinApplied.com

Universal I/O Status Menu
The Universal I/O Status Menu provides diagnostic information
to qualied service personnel. The items listed in this menu
will provide current status information of the Universal inputs
& outputs. If the universal I/O is congured for resistance,
the value will be displayed in 1/10th ohm scale. If the I/O is
congured for mA, the value will be displayed in micro amps
(1 mA = 1000 micro amps). If I/O is congured for voltage, the
value is displayed in 1/1000th volt scale. Example: MCB-X7
(OA Damper analog output) shows a value of 3000, this would
translate into 3 VDC.
Table 24: Universal I/O Status Menu
Item Display
Name
Default
Setting
Range
Password
Level
MCB X1= — 0 – 9999999 2
MCB X2= — 0 – 9999999 2
MCB X3= — 0 – 9999999 2
MCB X4= — 0 – 9999999 2
MCB X5= — 0 – 9999999 2
MCB X6= — 0 – 9999999 2
MCB X7= — 0 – 9999999 2
MCB X8= — 0 – 9999999 2
EMD X1= — 0 – 9999999 2
EMD X2= — 0 – 9999999 2
EMD X3= — 0 – 9999999 2
EMD X4= — 0 – 9999999 2
EMD X5= — 0 – 9999999 2
EMD X6= — 0 – 9999999 2
EMD X7= — 0 – 9999999 2
EMD X8= — 0 – 9999999 2
Digital Input Status Menu
The Digital Input Status Menu provides diagnostic information
to qualied service personnel. The items listed in this menu
will provide current status information of the controller’s digital
inputs.
Table 25: Digital Input Status Menu
Item Display
Name
Default Setting Range Password Level
MCB DI1= O󰀨 O󰀨/On 2
MCB DI2= O󰀨 O󰀨/On 2
MCB DI3= O󰀨 O󰀨/On 2
MCB DI4= O󰀨 O󰀨/On 2
MCB DI5= O󰀨 O󰀨/On 2
MCB DI6= O󰀨 O󰀨/On 2
EMB DI1= O󰀨 O󰀨/On 2
EMB DI1= O󰀨 O󰀨/On 2
EMD DI4= O󰀨 O󰀨/On 2
Digital Output Status Menu
The Digital Output Status Menu provides diagnostic
information to qualied service personnel. The items listed
in this menu will provide current status information of the
controller’s digital outputs.
Table 26: Digital Output Status Menu
Item Display
Name
Default
Setting
Range
Password
Level
MCB DO1= O󰀨 O󰀨/On 2
MCB DO2= O󰀨 O󰀨/On 2
MCB DO3= O󰀨 O󰀨/On 2
MCB DO4= O󰀨 O󰀨/On 2
MCB DO5= O󰀨 O󰀨/On 2
MCB DO6= O󰀨 O󰀨/On 2
MCB DO7= O󰀨 O󰀨/On 2
MCB DO8= O󰀨 O󰀨/On 2
MCB DO9= O󰀨 O󰀨/On 2
MCB DO10= O󰀨 O󰀨/On 2
EMD DO1= O󰀨 O󰀨/On 2
EMD DO2= O󰀨 O󰀨/On 2
EMD-DO3= O󰀨 O󰀨/On 2
EMD-DO4= O󰀨 O󰀨/On 2
EMD DO5= O󰀨 O󰀨/On 2
EMD DO6= O󰀨 O󰀨/On 2
