Daikin MicroTech III DPS User Manual

OM 1263 • MICROTECH UNIT CONTROLLER 38 www.DaikinApplied.com


Trending Menus
The Trending Menus allow for setting up and managing onboard
trending of up to 30 data points within the controller. This data
can then be exported to an SD card. The trending memory will
begin over-writing the oldest existing data in the controller’s
memory when the allocated trending memory lls up. If an
SD card is installed in the controllers SD card reader slot, an
automatic export of the data will occur every night at midnight.
Table 30: Trending Menu
Item Display
Name
Default Setting Range Password Level
Trending Ena= No No/Yes 2
Apply Chgs= No No/Yes 2
Sample Time= 300s 1-3600s 2
TrendOnO󰀨= O󰀨 O󰀨/On 2
AutoExpTime= 1440m 0-1440m 2
Export Data= No No/Yes 2
Clear Trend= Done
Done 2
ClrData 2
ClrCfg 2
TrendFull= Wrap Wrap/Stop 2
DefaultTrend= No No/Yes 2
Trending Ena is an adjustable item which enables and
disables the on board trending function.
Apply Changes is an adjustable item which must be set to
make changes to trending point denitions and sampling rate
take e󰀨ect.
Sample Time is an adjustable item used to the sampling rate
for trending data points.
󰀨 is an adjustable item which starts and stops the
on board trending function.
AutoExpTime is the length of time a trend is to be captured
Export Data is an adjustable item which initiates a manual
export of the current on board trend data to an SD card.
Clear Trend is an adjustable item used to either clear only the
current trend data or the entire trend conguration.
TrendFull is a writable input that allows the user to dene
once the trend is recorded to either stop recording or begin to
overwright the beginning of the trend
DefaultTrend is a status to reset all trend reading back to the
unit default settings or not.
Default
There are thirty default trend points for ROC. They will only not
be recorded if manually programmed not to record.
Table 31: Default Trends Menu
Item Display
Name
Default Setting Range Password Level
Point 1= INV% INV% 2
Point 2= STDOut STDOut 2
Point 3= SAF% SAF% 2
Point 4= EF% EF% 2
Point 5= OAD% OAD% 2
Point 6= RH% RH% 2
Point 7= H/COut H/COut 2
Point 8= OAT OAT 2
Point 9= ClgSt ClgSt 2
Point 10= HtgSt HtgSt 2
Point 11= Cap%In Cap%In 2
Point 12= INVCmd INVCmd 2
Point 13= CmpInLk CmpInLk 2
Point 14= PTD PTD 2
Point 15= PTS PTS 2
Point 16= EVI% EVI% 2
Point 17= EVO% EVO% 2
Point 18= OAFCmd OAFCmd 2
Point 19= OF1Spd OF1Spd 2
Point 20= OF2Spd OF2Spd 2
Point 21= Tc Tc 2
Point 22= TcSpt TcSpt 2
Point 23= DSH DSH 2
Point 24= Te g Teg 2
Point 25= SSH SSH 2
Point 26= SSHSpt SSHSpt 2
Point 27= HDRT1 HDRT1 2
Point 28= HDRT3 HDRT3 2
Point 29= OilSts OilSts 2
Point 30= OilMng OilMng 2
