The following is a description of the MicroTech III menu structure. These menus and items can all be displayed with the keypad/
display. Menu items displayed will change based on the selected unit conguration.
Figure 7: Main Menu – Keypad/Display Menu Structure
For more detail go to:
Figure 8, page 12
For more detail go to:
Figure 12, page 16
For more detail go to:
Figure 5, page 8
For more detail go to:
Figure 12, page 16
Main Menu
Enter Password

Quick Menu

View/Set Unit

System Mode= Local
Heat/Cool In= Heat/Cool
CmpIntrLock=
Dehum Status=
Commission Unit

Manual Control

Service Menus

Unit Maintenance

Unit Conguration

Alarm Lists

About This Unit

See page 17 — 17
Quick Menu
System Mode= Local
Heat/Cool In= Heat/Cool
CmpIntrLock=
Dehum Status=________
Clg Capacity= XXX%
OAD/Econ Cap= XXX%
Htg Capacity= XXX%
Reheat Cap= XXX%
SAF Speed= XXX%
RF/EF Cap= XXX%
OA Temp= XXX°F
See page 31 — 31
Manual Control
Manual Control= Normal
Supply Fan= O󰀨
SAF Spd Cmd= 0%
SAF Spd Cmd= 0%
INV/OF Ena= O󰀨
INV Cmp= O󰀨
INV Spd Cmd= 0%
Comp 3= O󰀨
OA Fan= O󰀨
OA Fan Cmd= 0%
4 Way Valve= O󰀨
RcvSol Valve=O󰀨
BP Sol Valve= O󰀨
EVI Cmd= 0%
EVO Cmd= 0%
RF/EF Fan= O󰀨
RF/EF Spd Cmd= 0%
OAD/Econo= 0%
Reheat Valve= 0%
RH Output= Off
Alm Output= O󰀨
See page 39
About This Unit
SO_Item= 123456_12345
Unit SN= FBOU123456789
App Version= 2506017xxx
Cf1-15= xxxxxxxxxxxxxxxx
Cf6-29= xxxxxxxxxxxxxxxx
HMI GUID=
xxxxxxxx-xxxx-xxxx-xxxx-
xxxxxxxxxxxx
OBH GUID=
xxxxxxxx-xxxx-xxxx-xxxx-
xxxxxxxxxxxx
See page 32
Unit Maintenance
Operating Hours
See page 18 — 21
View/Set Unit
Unit Status/Settings

Temperatures

Flow Status

SAF Spd Control

RF/EF Control

Date/Time/Schedules

See page 8
Enter Password
Enter Password *******

See page 36
Unit Conguration
Apply Changes= No
Unit Type= DPS/DAH(3)
Control Type= RefOnly(3)
Clg Type= INV(4)
Comp Cong= 1V1F1C(M)
Gen Clg Stgs= NA
Low Ambient= NA(0)
Cond Ctrl= INV(8)
OA Dmpr/Econ= AirEc(3)
OA Flow Stn= None(0)
Htg Type= None(0)
Htg Stages= 1
Max Heat Rise= 100
SAF Type= EBMVAV(F)
RAF Type= None(0)
RF/EF Ctrl= NA(0)
2ndDSPSnsr= NA(0)
EFT/LCT Snsr= NA(0)
Enrgy Rec= None(0)
Clg Circ Type= 1Air(2)
Head P Ctrl= NA(0)
Bypass Ctrl= NA(0)
Unit Size= 012
Refrig Type= R410A(2)
Reheat Type= None(0)
Unit Voltage= 460V/60Hz(2)
EV Type= EVBSag(1)
Apply Changes= No
See page 22 — 30
Commission Unit
Unit Set-Up

Timer Settings

SAF Set-Up

RF/EF Set-Up

INV Cmp Set-Up

OA Fan Set-Up

Exp Valve Set-Up

Defrost Set-Up

Alarm/Event Cong

See page 32 — 35
Service Menus
Timer Settings

Operating Hours

Save/Restore Settings

Active Alarms

Alarm Log

Event Log

Alarm/Event Cong

Analog Input Status

Universal I/O Status

Digital Input Status

Digital Output Status

Modbus Status

IP Set-up

HMI Set-up

Sensor O󰀨sets

See page 16
Alarm Lists
Active Alarms

Alarm Log

