Daikin MicroTech III DPS User Manual


www.DaikinApplied.com 17 OM 1263 • MICROTECH UNIT CONTROLLER

Items in the Quick Menu (see Table 2) contain basic unit operating status and control set point parameters. The items shown in the
Quick Menu are Read Only if a valid password has not been entered. The following are brief descriptions of the Quick Menu items.
No password is required to view the Quick Menu.
Table 2: Quick Menu
Menu Display Name Default Setting Range Password Level
System Mode Local Local/Remote 6
Heat/Cool In Heat/Cool Heat/Cool 6
CmpIntrLock — Open/Closed 6
Dehum Status — Active/Inactive 6
Clg Capacity — 0 – 100% None
OAD/Econo Cap — 0 – 100% None
Htg Capacity — 0 – 100% None
Reheat Capacity — 0 – 100% None
SAF Speed — 0 – 100% None
RF/EF Cap — 0 – 100% None
OA Temp — -50.0 – 200.0°F None
System Mode is an adjustable item that sets the status for
the for the unit to run on local with eld inputs are ignored or
remote where operation is based on eld inputs
Heat/Cool In is an adjustable item that only applicable
on heatpump units to determine DX cooling or heatpump
operation
CmpInterLock is an adjustable input safety that can be used
to prevent compressor operation based on external system
safeties
Dehum Status is a status only item which indicates the status
of operation of the dehumidier. The dehumidier can be active
or inactive.
Clg Capacity is a status only item which indicates the
percentage of the unit maximum cooling capacity currently
operating.
OAD/Econo Cap is a status only item which indicates the
percentage that the outdoor damper or economizer valve is
currently open.
Htg Capacity is a status only item which indicates the
percentage of the unit maximum heating capacity currently
operating.
Reheat Capacity is a status only item which indicates the
percentage of the unit maximum reheat capacity currently
operating.
SAF Capacity is a status only item which indicates the
capacity of the supply air fan.
RF/EF Capacity is a status only item indicating the capacity of
the return fan/exhaust air fans.
OA Temp is a status only item which displays the current
temperature reading from the unit mounted outdoor air
temperature sensor. This sensor is standard on all units.
