Temperature Menu
Menus in the Temperatures menu contain unit temperature status information.
Table 4: Temperature Menu
Item Display Name Default Setting Range Password Level
OA Temp= — -50.0 – 200.0°F 6
DRT1= — -50.0 – 392.0°F 6
DRT3= — -50.0 – 392.0°F 6
SRT= — -50.0 – 200.0°F 6
DFT= — -50.0 – 200.0°F 6
IRT= — -50.0 – 150.0°F 6
ORT= — -50.0 – 150.0°F 6
INVCompTemp= — -50.0 – 392.0°F 2
OA Temp is a status only item which displays the current
temperature reading from the unit mounted outdoor air
temperature sensor.
DRT1 is a status only item which displays the current inverter
compressor discharge refrigerant line temperature sensor
reading.
DRT3 is a status only item which displays the current xed
compressor (Comp 3) discharge refrigerant line temperature
sensor reading.
SRT is a status only item which displays the current suction
refrigerant line temperature sensor reading.
DFT (Heat Pump only) is a status only item which displays the
current defrost temperature sensor reading.
IRT (Heat Pump only) is a status only item which displays the
current indoor refrigerant temperature sensor reading.
ORT (Heat Pump only) is a status only item which displays the
current outdoor refrigerant temperature sensor reading.
INVCompTemp (15 ton unit size only) is a status only
item which displays the current inverter compressor body
temperature sensor reading.
Flow Status Menu
Table 5: Flow Status Menu
Item Display
Name
Default Setting Range Password Level
Supply Fan= —
O󰀨
6
On
Ret/Exh Fan= —
O󰀨
6
On
Supply Fan is a status only item that indicates the current S/S
state of the supply fan.
Ret/Exh Fan is a status only item that indicates the current S/S
state of the exhaust or return fan.
RF/EF Control Menu
Table 6: Return/Exhaust Fan Speed Menu
Item Display
Name
Default Setting Range Password Level
RF/EF Cap= — 0 – 100% 6
RF/EF Spd Cmd= — 0 – 100% 6
RF/EF Cap is a status only item which indicates the current
exhaust fan capacity.
RF/EF Spd Cmd is an adjustable input to command the return/
exhaust fan speed.
SAF Spd Control Menu
Table 7: Supply Fan Speed Menu
Item Display
Name
Default Setting Range Password Level
SAF Speed= — 0 – 100% 6
SAF Spd Cmd= — 0 – 100% 6
SAF Speed is a status only item that indicates the current
supply fan speed.
Speed Cmd is a status only item that indicates the current
supply fan commanded speed.
