DISASSEMBLY
101Dana IncorporatedTSM-0238 - 6000 Transmission Service Manual
FIGURE 20: Using special tool AS0010012800 (see drawing
AS0010012800 p. 153), push belleville washers down and re-
move snapring.
FIGURE 21: Remove snapring, spacer, Belleville washers
and spacer.
FIGURE 22: Remove piston, use two guide pins.
FIGURE 23: Remove clutch-assembly using special tool
TG1500106700 (see drawing TG1500106700 p. 149).
