DISASSEMBLY
Dana Incorporated TSM-0238 - 6000 Transmission Service Manual
FIGURE 16: Remove endplate.
FIGURE 17: Remove discs + shims.
FIGURE 18: Remove snap-ring.
Removal of the snap rings can cause personal injuries. You
must wear appropriate safety equipment. To avoid injury to
eyes, wear eye protection equipment.
MANDATORY PROCEDURE
Set the pliers following the correct procedure shown in
p. 64.
FIGURE 19: Remove spacer.
