DANA SPICER 6000 EHO - Page 99

DISASSEMBLY
99Dana IncorporatedTSM-0238 - 6000 Transmission Service Manual
FIGURE 12: Remove gasket.
FIGURE 13: Remove snap-ring.
Removal of the snap rings can cause personal injuries. You
must wear appropriate safety equipment. To avoid injury to
eyes, wear eye protection equipment.
MANDATORY PROCEDURE
Set the pliers following the correct procedure shown in
p. 64.
WARNING
CAUTION
FIGURE 14: Remove snap-ring.
Removal of the snap rings can cause personal injuries. You
must wear appropriate safety equipment. To avoid injury to
eyes, wear eye protection equipment.
MANDATORY PROCEDURE
Set the pliers following the correct procedure shown in
p. 64.
FIGURE 15: Remove hub-assembly.
WARNING
CAUTION
