Fill oil before using the cutter. REMEMBER, replenishing the
oil when the top of the oil can be seen in the glass (14.5). It
is important that the glass does not run out of oil, as this will
damage the Grinder and impair its performance.
Only use pneumatic oil (Part number: DCHY29307)
Thelter(PartnumberP57106)inthewaterseparator(14.4)
must be changed as necessary. In case of problems with the
airsupply,cleanthelterifnecessary.
1. Air outlet for camera cleaner tank
2. Automaticwaterseparatorwithairltercartridge
(item no. P57106)
3. Air inlet from compressor
4. Automatic water separator
7.1.1 Water separator and oil lubricator
The mist lubricator must not be adjusted, as this has been con-
guredatthefactory.Themistlubricatormustbekeptupright
during transport. If the rack is placed on its side, the glass must
beremovedtopreventoilowingintothecameratank.
DURING transport with the device, always close the tap at the
air outlet for the camera tank.
5. Adjusting screw for oil lubricator (preset at the factory)
6. Air outlet for sluice/cutter
7. Automatic oil lubricator
8. Oiltank(remembertollwithpneumatic
oil, item no. DCHY29307)
5
1
2
3
4
6
7
8
