Danfoss DSH Series Application Guide

Figure 10: Outline drawing number 1
Ø D
H1
Ø19.05mm
(0.75 inch)
L3
L2
190.5mm
(7.5 inch)
190.5mm (7.5 inch)
L1
30°
H2
H
30°
CC-000055
Figure 11: Outline drawing number 2
Ø D
H
H2
H1
L1
L3
L2
8556208
Figure 12: Outline drawing number 3
H
H2
H1
Ø D
L2
L3
L1
8556199
Dimensions
Single compressors
Table 14: Single compressors
Compressor model
Motor volt‐
age code
D
H
H1
H2
L1
L2
L3
Outline drawing
number
mm
inch
mm
inch
mm
inch
mm
inch
mm
inch
mm
inch
mm
inch
DSH090
3, 4, 7, 9
243
9.57
485
19.09
235
9.25
451
17.76
180
7.09
230
9.06
230
9.06
1
8560176
DSH105-120-140-161
3
(1)
, 4, 7, 9
243
9.57
542
21.34
278
10.94
509
20.04
180
7.09
230
9.06
230
9.06
1
8560177
DSH140-161
3
243
9.57
542
21.34
278
10.94
509
20.04
201
7.91
230
9.06
230
9.06
1
8560246
DSH184
4/3,7,9
243
9.57
558
21.97
299
11.77
524
20.63
180 /
201
7.09 /
7.91
230
9.06
230
9.06
1
8560234 /
8560235
DSH240
3, 4, 7, 9
320
12.6
653
25.71
302
11.87
618
24.33
427
16.81
371
14.61
371
14.61
2
8556208
DSH295
3, 4, 7, 9
320
12.6
653
25.71
302
11.87
618
24.33
427
16.81
371
14.61
371
14.61
2
8556208
DSH381
4, 7, 9
333
13.11
726
28.58
302
11.87
667
26.26
429
16.89
371
14.61
371
14.61
3
8556199
DSH381
3
333
13.11
726
28.58
302
11.87
667
26.26
478
18.82
371
14.61
371
14.61
3
8556239
DSH485
4, 7, 9
333
13.11
726
28.58
302
11.87
667
26.26
429
16.89
371
14.61
371
14.61
3
8556198
DSH485
3
333
13.11
726
28.58
302
11.87
667
26.26
446
17.56
371
14.61
371
14.61
3
8556237
DSH600
4, 7, 9
333
13.11
799
31.46
302
11.87
732
28.82
429
16.89
371
14.61
371
14.61
3
8556192
(1)
DSH105-120
(1)
DSH105-120
© Danfoss | Climate Solutions | 2022.10 AB288965961751en-001402 | 21
Scroll compressors, DSH090 to DSH600 | Dimensions
