Danfoss ERC 102 User Manual

20
ERC menu
code
Default Min Max Unit Conv Unit Scale Default Access
Shop Ser OEM
Assignments ASi
S1 Config S1C Stn Stn dig no -- -- RW
S2 Config S2C Stn Stn dig no -- -- RW
S3 Config S3C Stn Stn dig no -- -- RW
S1 Application S1A SCo nC doo no -- -- RW
S2 Application S2A nC nC doo no -- -- RW
S3 Application S3A nC nC doo no -- -- RW
DI Config diC dio doC dio no -- -- RW
DO1 Config 01C CoP CoP HEt no -- -- RW
DO2 Config o2C dEF 0 Lig no -- -- RW
DO3 Config o3C FAn 0 Lig no -- -- RW
DO4 Config o4C dEF 0 Lig no -- -- RW
Button 1 Short Config b1C noP tP noP no -- -- RW
Button 1 Long Config b1L PoF tP PoF no -- -- RW
Button 2 Short Config b2C dEF tP noP no -- -- RW
Button 3 Short Config b3C tP tP noP no -- -- RW
Button 3 Long Config b3L ECo tP PoF no -- -- RW
Button 4 Short Config b4C tn tP noP no -- -- RW
Button 4 Long Config b4L Lig tP PoF no -- -- RW
Password level1 PS1 0 0 999 no RW RW RW
Password level2 PS2 0 0 999 no -- -- RW
Password level3 PS3 0 0 999 no -- -- RW
Cabinet Light Control
Source
CLC Lig Lig LEC no -- -- RW
Light off delay Lod 0 0 300 no Sec 1 -- -- RW
ERC 102 Reference manual – 6 CONFIGURATION OF INPUTS AND OUTPUTS
