6
Door sensor connector cable: please see Appendix II
for lengths and code numbers.
NOTE: Door sensor: is optional and is a connector
and cable with spade terminals compatible with door
contacts used in refrigeration applications.
Clips: are used to secure the ERC 102 in place in
the case of rear mounting. They are not used with
front mounting. There are two identical clips, one
placed on either side of the ERC 102. See Chapter 4
– Mounting – for further details.
Light sensor: is optional and is used to measure the
level of ambient light around the cabinet so
that night and day (Economy / Normal) modes
of operation can automatically be set, as well
as the brightness of the display.
Power plug: for laboratory use, low quantity
OEM production or whenever spade connectors are
not available.
ERC 102 Reference manual –
2 CONTENT OF THE BOX
