Danfoss FC 300 User Manual

P30K P37K P45K P55K P75K
High/Normal Load* HO NO HO NO HO NO HO NO HO NO
Typical Shaft output at 550 V
[kW]
22 30 30 37 37 45 45 55 55 75
Typical Shaft output at 575 V
[hp]
30 40 40 50 50 60 60 75 75 100
Typical Shaft output at 690 V
[kW]
30 37 37 45 45 55 55 75 75 90
Enclosure IP21, IP55 C2 C2 C2 C2 C2
Output current
Continuous (3x525-550 V) [A] 36 43 43 54 54 65 65 87 87 105
Intermittent (60 s overload)
(3x525-550 V) [A]
54 47.3 64.5 59.4 81 71.5 97.5 95.7 130.5 115.5
Continuous (3x551-690 V) [A] 34 41 41 52 52 62 62 83 83 100
Intermittent (60 s overload)
(3x551-690 V) [A]
51 45.1 61.5 57.2 78 68.2 93 91.3 124.5 110
Continuous KVA (at 550 V) [KVA] 34.3 41.0 41.0 51.4 51.4 61.9 61.9 82.9 82.9 100.0
Continuous KVA (at 575 V) [KVA] 33.9 40.8 40.8 51.8 51.8 61.7 61.7 82.7 82.7 99.6
Continuous KVA (at 690 V) [KVA] 40.6 49.0 49.0 62.1 62.1 74.1 74.1 99.2 99.2 119.5
Max. input current
Continuous (at 550 V) [A] 36 49 49 59 59 71 71 87 87 99
Continuous (at 575 V) [A] 54 53.9 72 64.9 87 78.1 105 95.7 129 108.9
Additional specifications
Max. cable cross section (mains
and motor) [mm
2
(AWG)]
150 (300 MCM)
Max. cable cross section (load
share and brake) [mm
2
(AWG)]
95 (3/0)
Max cable size with mains
disconnect [mm
2
(AWG)]
2)
95, 70, 70
(3/0, 2/0, 2/0)
185, 150, 120
(350 MCM, 300
MCM, 4/0)
-
Estimated power loss
at rated max. load [W]
4)
480 592 720 880 1200
Weight, enclosure IP21, IP55 [kg] 65
Efficiency
4)
0.98 0.98 0.98 0.98 0.98
Table 10.12 C2 Frame,
Mains Supply 3x525-690 V AC IP21/IP55 - NEMA 1/NEMA 12 (FC 302 only)
Specifications
VLT
®
AutomationDrive Operating
Instructions
MG33AM02 - VLT
®
is a registered Danfoss trademark 75
10
10

Danfoss FC 300 Specifications

General

Enclosure	IP20
Approvals	cUL, UL, CE
EMC filter	Built-in
Communication Options	CANopen, PROFIBUS DP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Output Voltage	0-100% of supply voltage
