Danfoss FC 300 User Manual

P11K P15K P18K P22K
High/Normal Load
1)
HO NO HO NO HO NO HO NO
Typical Shaft output at 550 V [kW] 7.5 11 11 15 15 18.5 18.5 22
Typical Shaft output at 575 V [hp] 11 15 15 20 20 25 25 30
Typical Shaft output at 690 V [kW] 11 15 15 18.5 18.5 22 22 30
Enclosure IP21, IP55 B2 B2 B2 B2
Output current
Continuous (3x525-550 V) [A] 14 19 19 23 23 28 28 36
Intermittent (60 s overload) (3x525-550
V) [A]
22.4 20.9 30.4 25.3 36.8 30.8 44.8 39.6
Continuous (3x551-690 V) [A] 13 18 18 22 22 27 27 34
Intermittent (60 s overload) (3x551-690
V) [A]
20.8 19.8 28.8 24.2 35.2 29.7 43.2 37.4
Continuous KVA (at 550 V) [KVA] 13.3 18.1 18.1 21.9 21.9 26.7 26.7 34.3
Continuous KVA (at 575 V) [KVA] 12.9 17.9 17.9 21.9 21.9 26.9 26.9 33.9
Continuous KVA (at 690 V) [KVA] 15.5 21.5 21.5 26.3 26.3 32.3 32.3 40.6
Max. input current
Continuous (3x525-690 V) [A] 15 19.5 19.5 24 24 29 29 36
Intermittent (60 s overload) (3x525-690
V) [A]
23.2 21.5 31.2 26.4 38.4 31.9 46.4 39.6
Additional specifications
Max. cable cross section (mains, load
share and brake) [mm
2
(AWG)]
35,-,- (2,-,-)
Max. cable cross section (motor) [mm
2
(AWG)]
35, 25, 25 (2, 4, 4)
Max cable size with mains disconnect
[mm
2
(AWG)]
2)
16,10,10 (6,8, 8)
Estimated power loss at rated max.
load [W]
4)
228 285 335 375
Weight, enclosure IP21, IP55 [kg] 27
Efficiency
4)
0.98 0.98 0.98 0.98
Table 10.11 B2 Frame,
Mains Supply 3x525-690 V AC IP21/IP55 - NEMA 1/NEMA 12 (FC 302 only)
Specifications
VLT
®
AutomationDrive Operating
Instructions
74 MG33AM02 - VLT
®
is a registered Danfoss trademark
10
10

Danfoss FC 300 Specifications

General

Enclosure	IP20
Approvals	cUL, UL, CE
EMC filter	Built-in
Communication Options	CANopen, PROFIBUS DP
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Output Voltage	0-100% of supply voltage
