Below are formulas to calculate pressure level dependent on input current:
Voltage All sizes (mA) Variables:
12 V I
PCOR
= – 2.724 x P
PCOR
+ 1453.8
P
PCOR
= PCOR pressure level (bar)
I
PCOR
= Current input to proportional PCOR solenoid (mA)
24 V I
PCOR
= – 1.399 x P
PCOR
+ 735.7
Proportional solenoid data C6
Description 12 V 24 V
Maximum current
1800 mA 920 mA
Nominal coil resistance
@ 20 °C [68 °F]
3.66 Ω 14.20 Ω
@ 80 °C [176 °F]
4.52 Ω 17.52 Ω
Inductance
33 mH 140 mH
PWM
Range
70-200 Hz
Frequency (preferred)
*
100 Hz
IP Rating
IEC 60 529
IP 67
DIN 40 050, part 9
IP 69K with mating connector
Connector color
Black
*
PWM signal required for optimum control performance.
Technical Information
H1 Bent Axis Variable Displacement Motors, Size 060/080/110/160/210/250
Controls – nomenclature, description
©
Danfoss | December 2016 11037153 | BC00000043en-US1103 | 63
