Options K1K1 and K2K2 (Electric proportional control with PCOR and BPD)
P003 459
Y
AB
ED
EB
Y
EA
EC
X
118.7
[4.67]
79.8
[3.14]
X
1
2
1
3
4
1. Connector: DEUTSCH DT04-2P
2. BPD solenoid
3. PCOR adjustment
4. Proportional solenoid
SAE mounting flange per ISO 3019/1 dimensions (mm [in])
Size 060
SAE 127-4
Size 080
SAE 127-4
Size 110
SAE 152-4
Size 160
SAE 152-4
Size 210
SAE 165-4
Size 250
SAE 165-4
AB
224.2 [8.83] 235.7 [9.28] 247.2 [9.73] 265.0 [10.43]
279.4 [11]
290.0 [11.42]
EA
126.1 [4.96] 138.8 [5.46] 160.7 [6.33] 180.4 [7.10]
199.9 [7.87]
213.0 [8.39]
EB
172.2 [6.78] 183.6 [7.23] 195.1 [7.68] 212.8 [8.38]
227.5 [8.96]
238.0 [9.37]
EC
164.8 [6.49] 177.4 [6.98] 199.4 [7.85] 219.0 [8.62]
238 [9.37]
251.0 [9.88]
ED
144.5 [5.69] 156.0 [6.14] 167.5 [6.59] 185.1 [7.29]
200.6 [7.9]
210.0 [8.27]
DIN B4 HL mounting flange per ISO 3019/2 dimensions, (mm [in])
Size 060 – DIN 125 Size 080 – DIN 140 Size 110 – DIN 160 Size 160 – DIN 180 Size 210 – DIN 200
AB
224.2 [8.83] 235.7 [9.28] 247.2 [9.73] 265.0 [10.43]
279.4 [11]
EA
101.6 [4.0] 114.8 [4.52] 128.2 [5.05] 148.5 [5.85]
167.9 [6.61]
EB
172.2 [6.78] 183.6 [7.23] 195.1 [7.68] 212.8 [8.38]
227.5 [8.96]
EC
140.3 [5.52] 153.4 [6.04] 166.9 [6.57] 187.1 [7.37]
206.0 [8.11]
ED
144.5 [5.69] 156.0 [6.14] 167.5 [6.59] 185.1 [7.29]
200.6 [7.9]
Size 250 is not available.
Cartridge mounting flange dimensions (mm [in])
Size 060
Cartridge 160
Size 080
Cartridge 190
Size 110
Cartridge 200
Size 160
Cartridge 200
AB
224.2 [8.83] 235.7 [9.28] 247.2 [9.73] 265.0 [10.43]
EA
41.9 [1.65] 36.4 [1.43] 46.2 [1.82] 66.1 [2.60]
EB
172.2 [6.78] 183.6 [7.23] 195.1 [7.68] 212.8 [8.38]
EC
80.6 [3.17] 75.0 [2.95] 84.9 [3.34] 104.7 [4.12]
ED
144.5 [5.69] 156.0 [6.14] 167.5 [6.59] 185.1 [7.29]
Size 210 and 250 are not available.
Technical Information
H1 Bent Axis Variable Displacement Motors, Size 060/080/110/160/210/250
Dimensions – Controls on H1B motors
126 |
©
Danfoss | December 2016 11037153 | BC00000043en-US1103
