Axial and radial ports dimensions, mm [in]
Measure
Size 060 Size 080 Size 110 Size 160 Size 210 Size 250
AA
265.0 [10.43] 283.2 [11.15] 311.0 [12.24] 339.7 [13.37]
363.9 [14.33]
381.0 [15.00]
AB
114.7 [4.52] 119.4 [4.70] 130.8 [5.15] 138.2 [5.44]
145.5 [5.73]
152.0 [5.98]
AC
224.2 [8.83] 235.7 [9.28] 247.2 [9.73] 265.0 [10.43]
279.4 [11]
290.0 [11.42]
BA
204.8 [8.06] 218.8 [8.61] 240.3 [9.46] 263.9 [10.39]
288.1 [11.34]
302.0 [11.89]
BB
32.3 [1.27] 34.7 [1.37] 37.5 [1.48] 42.0 [1.65]
46.4 [1.83]
48.0 [1.89]
BC
74.4 [2.93] 78.4 [3.09] 88.9 [3.50] 99.9 [3.93]
108.2 [4.26]
108.0 [4.25]
BF
220.5 [8.68] 236.7 [9.32] 263.4 [10.37] 289.2 [11.39]
312.1 [12.29]
329.0 [12.95]
BG
18.9 [0.74] 22.0 [0.87] 24.8 [0.98] 28.6 [1.13]
29.5 [1.16]
28.0 [1.1]
BH
204.7 [8.06] 218.8 [8.61] 240.3 [9.46] 263.9 [10.39]
288.1 [11.34]
302.0 [11.89]
BJ
32.3 [1.27] 34.7 [1.37] 37.5 [1.48] 42.0 [1.65]
46.4 [1.83]
48.0 [1.89]
BK
69.5 [2.74] 75.2 [2.96] 85.0 [3.35] 96.0 [3.78]
104.3 [4.11]
108.0 [4.25]
BL
50.8 [2.00] 57.2 [2.25] 57.2 [2.25] 66.6 [2.62]
66.6 [2.62]
66.6 [2.62]
BM
23.8 [0.94] 27.8 [1.09] 27.8 [1.09] 31.8 [1.25]
31.8 [1.25]
31.8 [1.25]
CA
243.7 [9.59] 258.7 [10.19] 282.6 [11.13] 306.9 [12.08]
327.9 [12.91]
345.0 [13.58]
CB
43.4 [1.71] 46.2 [1.82] 49.6 [1.95] 54.4 [2.14]
57.8 [2.28]
60.0 [2.36]
CC
48.0 [1.89] 50.0 [1.97] 50.0 [1.97] 60.0 [2.36]
65 [2.56]
65.0 [2.56]
CD
50.8 [2.00] 57.2 [2.25] 57.2 [2.25] 66.6 [2.62]
66.6 [2.62]
66.6 [2.62]
CE
23.8 [0.94] 27.8 [1.09] 27.8 [1.09] 31.8 [1.25]
31.8 [1.25]
31.8 [1.25]
CF
69.5 [2.74] 67.7 [2.67] 95.5 [3.76] 86.4 [3.40]
98.9 [3.89]
107.0 [4.21]
CG
85.8 [3.38] 90.0 [3.54] 96.0 [3.78] 102.2 [4.02]
108.5 [4.27]
112.0 [4.41]
CH
18.0 [0.71] 17.0 [0.67] 21.0 [0.83] 23.0 [0.91]
25 [0.98]
25.0 [0.98]
CJ
92.5 [3.64] 104.0 [4.09] 119.5 [4.70] 122.8 [4.83]
136.3 [5.37]
141.5 [5.57]
CK
70.0 [2.76] 75.0 [2.95] 83.0 [3.27] 96.5 [3.80]
103.5 [4.07]
107.5 [4.23]
CL
83.4 [3.28] 89.3 [3.52] 101.3 [3.99] 107.7 [4.24]
116.9 [4.6]
124.0 [4.88]
CM
89.3 [3.52] 93.7 [3.69] 97.2 [3.83] 105.6 [4.16]
111.2 [4.38]
130.0 [5.12]
CN
244.8 [9.64] 258.7 [10.19] 283.6 [11.17] 307.9 [12.12]
328.9 [12.95]
346.0 [12.83]
CO
43.7 [1.72] 46.2 [1.82] 49.9 [1.96] 54.6 [2.15]
58.1 [2.29]
61.0 [2.4]
CP
48.0 [1.89] 50.0 [1.97] 50.0 [1.97] 60.0 [2.36]
65 [2.56]
65.0 [2.56]
α
17° 17° 19° 17° 17° 17°
For further detailed information about SAE ports dimensions see the SAE flange design ports per ISO 11
926-1 on page 96.
Legend:
1 Loop flushing relief valve
2 Loop flushing shuttle spool
3 Speed sensor
4 Minimum angle stop adjustment
5 Connector: DT04-2P
6 Alternate position of case drain port
Technical Information
H1 Bent Axis Variable Displacement Motors, Size 060/080/110/160/210/250
Dimensions
©
Danfoss | December 2016 11037153 | BC00000043en-US1103 | 93
