Danfoss H1 Series User Manual

Axial and radial ports dimensions, mm [in]
Measure Size 060 Size 080 Size 110 Size 160 Size 210 Size 250
AA
243 [9.57] 261.4 [10.29] 288 [11.34] 314.9 [12.4]
341.1 [13.43]
359 [14.13]
AB
114.7 [4.52] 119.4 [4.7] 130.8 [5.15] 138.2 [5.44]
145.5 [5.73]
152 [5.98]
AC
193.6 [7.62] 206.6 [8.13] 224.1 [8.82] 242.5 [9.55]
257.7 [10.15]
267 [10.51]
AD
112.7 [4.44] 112.7 [4.44] 112.7 [4.44] 112.7 [4.44]
112.7 [4.44]
112.7 [4.44]
AE
max 67.3 [2.65] max 67.3 [2.65] max 67.3 [2.65] max 67.3 [2.65]
max 67.3 [2.65]
max 67.3 [2.65]
AF
254.3 [9.66] 263.5 [10.37] 290.4 [11.43] 314.9 [12.39]
341.1 [13.43]
359 [14.13]
BA
205.1 [8.07] 219.1 [8.63] 240.3 [9.46] 263.9 [10.39]
288.1 [11.34]
302 [11.89]
BB
32.3 [1.27] 34.7 [1.37] 37.5 [1.49] 42 [1.65]
46.4 [1.83]
48 [1.89]
BC
74.4 [2.93] 78.4 [3.09] 88.9 [3.5] 99.9 [3.93]
108.2 [4.26]
108 [4.25]
BD
189.8 [7.47] 198 [7.8] 220 [8.66] 243.9 [9.6]
268 [10.55]
281 [11.06]
BE
83.8 [3.30] 90.6 [3.57] 100.9 [3.97] 111.7 [4.4]
120.8 [4.76]
125 [4.92]
BH
205.1 [8.07] 218.8 [8.61] 240.3 [9.46] 263.9 [10.39]
288.1 [11.34]
302 [11.89]
BJ
32.3 [1.27] 34.7 [1.37] 37.5 [1.48] 42.0 [1.65]
46.4 [1.83]
48 [1.89]
BK
69.5 [2.74] 75.2 [2.96] 85.0 [3.35] 96.0 [3.78]
104.3 [4.11]
108 [4.25]
BL
50.8 [2.00] 57.2 [2.25] 57.2 [2.25] 66.6 [2.62]
66.6 [2.62]
66.6 [2.62]
BM
23.8 [0.94] 27.8 [1.09] 27.8 [1.09] 31.8 [1.25]
31.8 [1.25]
31.8 [1.25]
CA
233.8 [9.2] 250.2 [9.85] 276.8 [10.9] 298.9 [11.78]
323.1 [12.72]
338 [13.31]
CB
40.6 [1.6] 43.7 [1.72] 48 [1.89] 52.1 [2.05]
56.1 [2.21]
59 [2.32]
CC
48 [1.89] 50 [1.97] 50 [1.97] 60 [2.36]
65 [2.56]
65 [2.56]
CD
50.8 [2.00] 57.2 [2.25] 57.2 [2.25] 66.6 [2.62]
66.6 [2.62]
66.6 [2.62]
CE
23.8 [0.94] 27.8 [1.09] 27.8 [1.09] 31.8 [1.25]
31.8 [1.25]
31.8 [1.25]
CF
69.5 [2.74] 67.7 [2.67] 95.5 [3.76] 86.4 [3.40]
98.9 [3.89]
107 [4.21]
CG
85.8 [3.38] 90 [3.54] 96 [3.78] 102.2 [4.02]
108.5 [4.27]
112 [4.41]
CH
18 [0.71] 17 [0.67] 21 [0.83] 23 [0.91]
25 [0.98]
25 [0.98]
CJ
92.5 [3.64] 104 [4.09] 119.5 [4.70] 122.8 [4.83]
136.3 [5.37]
141.5 [5.57]
CK
70 [2.76] 75 [2.95] 83 [3.27] 96.5 [3.80]
103.5 [4.07]
107.5 [4.23]
CL
83.4 [3.28] 89.3 [3.52] 101.3 [3.99] 107.7 [4.24]
116.9 [4.6]
124 [4.88]
CM
89.3 [3.52] 93.7 [3.69] 97.2 [3.83] 105.6 [4.16]
111.2 [4.38]
130 [5.12]
CN
234.1 [9.22] 250.6 [9.87] 277.8 [10.94] 298.9 [11.78]
323.8 [12.75]
339 [13.35]
CO
40.7 [1.6] 43.8 [1.72] 48.2 [1.9] 52.3 [2.06]
56.6 [2.23]
59 [2.32]
CP
48 [1.89] 50 [1.97] 50 [1.97]
60 [2.36] 65 [2.56] 65 [2.56]
α
17° 17° 19° 17° 17° 17°
For further detailed information about SAE ports dimensions see the SAE flange design ports per ISO 11
926-1 on page 96.
Technical Information
H1 Bent Axis Variable Displacement Motors, Size 060/080/110/160/210/250
Dimensions
©
Danfoss | December 2016 11037153 | BC00000043en-US1103 | 95
