Danfoss H1 Series

Shaft dimensions; mm [in]
Shaft option
EN/ES AN/AS FN/FS BN/BS CN/CS DN/DS
Teeth
13 14 15 21 23 27
Module
8/16 12/24 8/16 16/32 16/32 16/32
Pitch-Ø
41.275 [1.625] 29.633 [1.167] 47.625 [1.875] 33.337 [1.312] 36.513 [1.438] 42.862 [1.687]
Spline
ANSI B92.1-1970 Class 5 flat root side fit
ØA
43.6 [1.717] 31.2 [1.228] 49.96 [1.966] 34.4 [1.315] 37.61 [1.48] 44.0 [1.732]
ØH
55.0 [2.165] 44.5 [1.752] 55.0 [2.165] 44.5 [1.752] 44.5 [1.752] 55.0 [2.165]
ØJ
36.0 [1.417] 25.8 [1.016] 42.2 [1.661] 30.0 [1.181] 32.0 [1.260] 39.6 [1.559]
DA
55.0 [2.165] 37.5 [1.476] 53.0 [2.087] 37.5 [1.476] 37.5 [1.476] 55.0 [2.165]
DB
67.0 [2.638] 47.5 [1.870] 67.0 [2.638] 47.5 [1.870] 47.5 [1.870] 67.0 [2.638]
DC
75.0 [2.953]
75.4 [2.968]
*
55.5 [2.185] 75.0 [2.953]
75.4 [2.968]
*
55.5 [2.185] 55.5 [2.185] 75.0 [2.953]
75.4 [2.968]
*
R
3.0 [0.118] 3.0 [0.118] 3.0 [0.118] 3.0 [0.118] 3.0 [0.118] 3.0 [0.118]
V
M12 M10 M16 M10 M12 M16
Angle
Pressure angle 30°
*
Size 160 only
For DIN 5480 shaft used in combination with SAE flanges, please contact your local Danfoss Power
Solutions representative.
