Danfoss MCB 152 User Manual

42-8* Status
Parameter Options/Valid
range
Default value Description Conversion
index
Data type
42-80 Safe Option
Status
0 - 0xFFFFFFFF 0 Shows the status word of the Safety Option
MCB 152 as a hexadecimal value. For more
information, see chapter 6.2 Status over
Fieldbus.
0 u_int32
42-81 Safe Option
Status 2
0 - 0x7FFFFFFF 0 Shows the status 2 word of the Safety Option
MCB 152 as a hexadecimal value. For more
information, see chapter 6.2 Status over
Fieldbus.
0 u_int32
42-82 Safe Control
Word
0 - 0xFFFFFFFF 0 Shows the safe control word as a hexadecimal
value.
- u_int32
42-83 Safe Status
Word
0 - 0xFFFFFFFF 0 Shows the safe status word as a hexadecimal
value.
- u_int32
42-85 Active Safe
Func.
[0] STO
[10] None
[10] None Shows the currently active safety function. Use
0-20 Display Line 1.1 Small to 0-22 Display Line
1.3 Small to show the function on the LCP.
- u_int8
42-86 Safe Option Info
Safe Option
Messages, String
Length 25
0 Shows information about the safety option.
The LCP can show this parameter in the large
display line.
Can be selected in 0-23 Display Line 2 Large
and 0-24 Display Line 3 Large.
0 Visible-
String
42-88 Supported
Customization File
Version
0.00 - 99.99 2.00 Shows the maximum supported configuration
file version (CfgFileVers):
[0] – the maximum version supported by the
safe system (frequency converter with the
safety option).
[1] – the maximum version supported by the
safety option.
[2] – the maximum version supported by the
control card.
-2 u_int16
42-89 Customization
File Version
0.00 - 99.99 2.00 Shows the currently used customisation file
version.
-2 u_int16
Table 7.4 42-8* Status
42-9* Special
Parameter Options/Valid
range
Default value Description Conversion
index
Data type
42-90 Restart Safe
Option
[0] No
[1] Yes
[0] No Select [1] Yes to restart the Safety Option MCB
152 without power cycling the frequency
converter. When the safe fieldbus is enabled
the communication option is also restarted.
- u_int8
Table 7.5 42-9* Special
Parameter Set-up
Operating Instructions
MG37F102 Danfoss A/S © 10/2014 All rights reserved. 29
7 7
