7 General Specications
Line power supply (L1, L2, L3)
Supply voltage 380–480 V ±10%
Supply voltage 525–690 V ±10%
AC line voltage low/line drop-out:
During low AC line voltage or a line drop-out, the adjustable frequency drive continues until the intermediate circuit voltage
drops below the minimum stop level. The stop level normally corresponds to 15% below the adjustable frequency drive’s lowest
rated supply voltage. Power-up and full torque cannot be expected at AC line voltage lower than 10% below the adjustable
frequency drive’s lowest rated supply voltage.
Supply frequency 50/60 Hz ±5%
Maximum imbalance temporary between line power phases 3.0% of rated supply voltage
True power factor (λ) ≥0.9 nominal at rated load
Displacement power factor (cosφ) near unity (> 0.98)
Switching on input supply L1, L2, L3 (power-ups) maximum once/2 min.
Environment according to EN60664-1 Overvoltage category III/pollution degree 2
The unit is suitable for use on a circuit capable of delivering not more than 100000 RMS symmetrical Amperes, 480/690 V
maximum.
7.1 Motor Output and Motor Data
Motor output (U, V, W)
Output voltage 0–100% of supply voltage
Output frequency 0–590
1)
Hz
Switching on output unlimited
Ramp times 1–3600 s
1) Voltage and power-dependent.
Torque characteristics
Starting torque (constant torque) maximum 110% for 1 min.
1)
Starting torque maximum 135% up to 0.5 s
1)
Overload torque (constant torque) maximum 110% for 1 min.
1)
1) Percentage relates to the adjustable frequency drive's nominal torque.
7.2 Ambient Conditions
Surroundings
Enclosure size E IP00, IP21, IP54
Enclosure size F IP21, IP54
Vibration test 1 g
Relative humidity 5%–95% IEC 721-3-3; Class 3K3 (non-condensing) during operation
Aggressive environment (IEC 721-3-3), coated 3C3
Test method according to IEC 60068-2-43 H
2
S
10 days
Ambient temperature (at 60 AVM switching mode)
- with derating maximum 55 °C (131 °F)
1)
- with full output power, typical EFF2 motors maximum 50 °C (122 °F)
1)
- at full continuous adjustable frequency drive output current maximum 45 °C (113 °F)
1)
1) For more information on derating, see the section on special conditions in the design guide.
Minimum ambient temperature during full-scale operation 0 °C (32 °F)
General Specications Instruction Manual
MG11F522 Danfoss A/S © 08/2014 All rights reserved. 113
7 7
