7.5 Electrical Data
Line Power Supply 3 x 380–480 V AC
P315 P355 P400 P450
Typical shaft output at 400 V [kW] 315 355 400 450
Typical shaft output at 460 V [hp] 450 500 600 600
Enclosure protection rating IP21 E1 E1 E1 E1
Enclosure protection rating IP54 E1 E1 E1 E1
Enclosure protection rating IP00 E2 E2 E2 E2
Output current
Continuous (at 400 V) [A] 600 658 745 800
Intermittent (60 s overload) (at 400 V)
[A]
660 724 820 880
Continuous (at 460/480 V) [A] 540 590 678 730
Intermittent (60 s overload) (at
460/480 V) [A]
594 649 746 803
Continuous KVA (at 400 V) [KVA] 416 456 516 554
Continuous KVA (at 460 V) [KVA] 430 470 540 582
Maximum input current
Continuous (at 400 V) [A] 590 647 733 787
Continuous (at 460/480 V) [A] 531 580 667 718
Maximum cable size, line power,
motor and load share [mm
2
(AWG
2)
)]
4 x 240
(4 x 500 mcm)
4 x 240
(4 x 500 mcm)
4 x 240
(4 x 500 mcm)
4 x 240
(4 x 500 mcm)
Maximum cable size, brake [mm
2
(AWG
2)
)
2 x 185
(2 x 350 mcm)
2 x 185
(2 x 350 mcm)
2 x 185
(2 x 350 mcm)
2 x 185
(2 x 350 mcm)
Maximum external pre-fuses [A]
1)
700 800 900 900
Estimated power loss
at rated max. load [W]
3)
, 400 V
6790 7701 8677 9473
Estimated power loss
at rated maximum load [W]
3)
, 460 V
6082 6953 7819 8527
Weight,
enclosure protection rating IP21, IP54
[kg (lb)]
263 (580) 270 (595.5) 272 (600) 313 (690)
Weight,
enclosure protection rating IP00 [kg
(lb)]
221 (487.3) 234 (516) 236 (520.3) 277 (611)
Eciency
4)
0.98
Output frequency 0–590 Hz
Heatsink overtemperature trip
110 °C (230 °F)
Power card ambient trip
75°C (167 °F) 85 °C (185 °F)
Table 7.1 Line Power Supply 3 x 380–480 V AC
General Specications
VLT
®
HVAC Drive FC 102
118 Danfoss A/S © 08/2014 All rights reserved. MG11F522
77
