Line Power Supply 3 x 380–480 V AC
P500 P560 P630 P710 P800 P1M0
Typical shaft output at 400 V [kW] 500 560 630 710 800 1000
Typical shaft output at 460 V [hp] 650 750 900 1000 1200 1350
Enclosure protection rating IP21,
IP54 without/with options cabinet
F1/F3 F1/F3 F1/F3 F1/F3 F2/F4 F2/F4
Output current
Continuous (at 400 V) [A] 880 990 1120 1260 1460 1720
Intermittent (60 s overload)
(at 400 V) [A]
968 1089 1232 1386 1606 1892
Continuous (at 460/480 V) [A] 780 890 1050 1160 1380 1530
Intermittent (60 s overload)
(at 460/480 V) [A]
858 979 1155 1276 1518 1683
Continuous KVA (at 400 V) [KVA] 610 686 776 873 1012 1192
Continuous KVA (at 460 V) [KVA] 621 709 837 924 1100 1219
Maximum input current
Continuous
(at 400 V) [A]
857 964 1090 1227 1422 1675
Continuous (at 460/480 V) [A] 759 867 1022 1129 1344 1490
Maximum cable size, motor [mm
2
(AWG
2)
)]
8 x 150
(8 x 300 mcm)
12 x 150
(12 x 300 mcm)
Maximum cable size, line power
F1/F2 [mm
2
(AWG
2)
)]
8 x 240
(8 x 500 mcm)
Maximum cable size, line power
F3/F4 [mm
2
(AWG
2)
)]
8 x 456
(8 x 900 mcm)
Maximum cable size, load sharing
[mm
2
(AWG
2)
)]
4 x 120
(4 x 250 mcm)
Maximum cable size, brake [mm
2
(AWG
2)
)
4 x 185
(4 x 350 mcm)
6 x 185
(6 x 350 mcm)
Maximum external pre-fuses [A]
1)
1600 2000 2500
Estimated power loss at rated
maximum load [W]
3)
, 400 V, F1 &
F2
10162 11822 12512 14674 17293 19278
Estimated power loss at rated
maximum load [W]
3)
, 460 V, F1 &
F2
8876 10424 11595 13213 16229 16624
Maximum added losses of A1 RFI,
circuit breaker or disconnect, &
contactor, F3 & F4
963 1054 1093 1230 2280 2541
Maximum panel options losses 400
Weight,
enclosure protection rating IP21,
IP54 [kg (lb)]
1017/1318 (2242.1/2905.7) 1260/1561 (2778/3441.5)
Weight rectier module [kg (lb)] 102 (224.9) 136 (300)
Weight inverter module [kg (lb)] 102 (224.9) 136 (300) 102 (224.9)
Eciency
4)
0.98
Output frequency 0–590 Hz
Heatsink overtemperature trip
95 °C (203 °F)
Power card ambient trip
85 °C (185 °F)
Table 7.2 Line Power Supply 3 x 380–480 V AC
General
Specications Instruction Manual
MG11F522 Danfoss A/S © 08/2014 All rights reserved. 119
7 7
