Line Power Supply 3 x 525–690 V AC
P450 P500 P560 P630
Typical shaft output at 550 V [kW] 355 400 450 500
Typical shaft output at 575 V [hp] 450 500 600 650
Typical shaft output at 690 V [kW] 450 500 560 630
Enclosure protection rating IP21 E1 E1 E1 E1
Enclosure protection rating IP54 E1 E1 E1 E1
Enclosure protection rating IP00 E2 E2 E2 E2
Output current
Continuous (at 550 V) [A] 470 523 596 630
Intermittent (60 s overload) (at 550 V)
[A]
517 575 656 693
Continuous (at 575/690 V) [A] 450 500 570 630
Intermittent (60 s overload) (at 575/
690 V) [A]
495 550 627 693
Continuous KVA (at 550 V) [KVA] 448 498 568 600
Continuous KVA (at 575 V) [KVA] 448 498 568 627
Continuous KVA (at 690 V) [KVA] 538 598 681 753
Maximum input current
Continuous (at 550 V) [A] 453 504 574 607
Continuous (at 575 V) [A] 434 482 549 607
Continuous (at 690 V) [A] 434 482 549 607
Maximum cable size, line power, motor
and load share [mm
2
(AWG)]
2x240 (2x500
mcm)
4x240 (4x500 mcm) 4x240 (4x500 mcm) 4x240 (4x500 mcm)
Maximum cable size, brake [mm
2
(AWG)]
2x185 (2x350
mcm)
2x185
(2x350 mcm)
2x185
(2x350 mcm)
2x185
(2x350 mcm)
Maximum external pre-fuses [A]
1)
700 700 900 900
Estimated power loss
at rated maximum load [W]
3)
, 600 V
5323 6010 7395 8209
Estimated power loss
at rated maximum load [W]
3)
, 690 V
5529 6239 7653 8495
Weight,
enclosure protection ratings IP21, IP54
[kg (lb)]
263 (580) 263 (580) 272 (600) 313 (690)
Weight, enclosure protection rating
IP00 [kg (lb)]
221 (487.3) 221 (487.3) 236 (520.3) 277 (611)
Eciency
4)
0.98
Output frequency 0–525 Hz
Heatsink overtemperature trip
110 °C (230
°F)
95 °C (203 °F)
110 °C (230 °F)
Power card ambient trip
85 °C (185 °F)
Table 7.3 Line Power Supply 3 x 525–690 V AC
General
Specications
VLT
®
HVAC Drive FC 102
120 Danfoss A/S © 08/2014 All rights reserved. MG11F522
