Line Power Supply 3 x 525–690 V AC
P710 P800 P900 P1M0 P1M2 P1M4
Typical shaft output at 550 V [kW] 560 670 750 850 1000 1100
Typical shaft output at 575 V [hp] 750 950 1050 1150 1350 1550
Typical shaft output at 690 V [kW] 710 800 900 1000 1200 1400
Enclosure protection ratings IP21, IP54
without/with options cabinet
F1/F3 F1/F3 F1/F3 F2/F4 F2/F4 F2/F4
Output current
Continuous (at 550 V) [A] 763 889 988 1108 1317 1479
Intermittent (60 s overload, at 550 V) [A] 839 978 1087 1219 1449 1627
Continuous (at 575/690 V) [A] 730 850 945 1060 1260 1415
Intermittent (60 s overload, at 575/690 V)
[A]
803 935 1040 1166 1386 1557
Continuous KVA (at 550 V) [KVA] 727 847 941 1056 1255 1409
Continuous KVA (at 575 V) [KVA] 727 847 941 1056 1255 1409
Continuous KVA (at 690 V) [KVA] 872 1016 1129 1267 1506 1691
Maximum input current
Continuous (at 550 V) [A] 743 866 962 1079 1282 1440
Continuous (at 575 V) [A] 711 828 920 1032 1227 1378
Continuous (at 690 V) [A] 711 828 920 1032 1227 1378
Maximum cable size, motor [mm
2
(AWG
2)
)]
8x150 (8x300 mcm) 12x150 (12x300 mcm)
Maximum cable size, line power F1/F2
[mm
2
(AWG
2)
)]
8x240 (8x500 mcm)
Maximum cable size, line power F3/F4
[mm
2
(AWG
2)
)]
8x456 (8x900 mcm)
Maximum cable size, load sharing [mm
2
(AWG
2)
)]
4x120 (4x250 mcm)
Maximum cable size, brake [mm
2
(AWG
2)
)
4x185 (4x350 mcm) 6x185 (6x350 mcm)
Maximum external pre-fuses [A]
1)
1600 2000 2500
Estimated power loss at rated maximum
load [W]
3)
, 600 V, F1 & F2
9500 10872 12316 13731 16190 18536
Estimated power loss at rated maximum
load [W]
3)
, 690 V, F1 & F2
9863 11304 12798 14250 16821 19247
Maximum added losses of circuit breaker
or disconnect & contactor, F3 & F4
427 532 615 665 863 1044
Maximum panel options losses 400
Weight, enclosure protection ratings IP21,
IP54 [kg (lb)]
1004/1299
(2213.5/2863.8
)
1004/1299
(2213.5/2863.8
)
1004/1299
(2213.5/2863.8)
1246/1541
(2747/3397.4)
1246/1541
(2747/3397.4)
1280/1575
(2822/3472.3)
Weight, rectier module [kg (lb)] 102 (224.9) 102 (224.9) 102 (224.9) 136 (300) 136 (300) 136 (300)
Weight, inverter module [kg (lb)] 102 (224.9) 102 (224.9) 136 (300) 102 (224.9) 102 (224.9) 136 (300)
Eciency
4)
0.98
Output frequency 0–500 Hz
Heatsink overtemperature trip
95 °C (203 °F)
105 °C (221 °F) 95 °C (203 °F) 95 °C (203 °F) 105 °C (221
°F)
95 °C (203 °F)
Power card ambient trip
85 °C (185 °F)
Table 7.4 Line Power Supply 3 x 525–690 V AC
1) For type of fuse, see chapter 4.1.14 Fuses.
2) American wire gauge.
