Danfoss Metasys N2 Instruction Manual

No. Description Warning Alarm/trip Alarm/trip lock Parameter reference
96 Start delayed X 22-7*
97 Stop delayed X 22-7*
98 Clock fault X 0-7*
201 Fire M was active
202 Fire M limits exceeded
203 Missing motor
204 Locked rotor
243 Brake IGBT X X
244 Heatsink temp X X X
245 Heatsink sensor X X
246 Pwr.card supply X X
247 Pwr.card temp X X
248 Illegal PS cong X X
250 New spare parts X
251 New type code X X
Table 8.1 Alarm/Warning Code List
(X) Dependent on parameter.
1) Cannot be auto reset via parameter 14-20 Reset Mode.
A trip is the action when an alarm has appeared. The trip
coasts the motor and can be reset by pressing [Reset] or
by using the Reset function via a digital input (parameter
group 5-1* Digital Inputs [1]). The original event that
caused an alarm cannot damage the adjustable frequency
drive or cause dangerous conditions. A trip lock is an
action when an alarm occurs, which may damage the
adjustable frequency drive or connected parts. A trip lock
situation can only be reset by power cycling.
Warning yellow
Alarm ashing red
Trip locked yellow and red
Table 8.2 LED Indication
Alarm Word and Extended Status Word
Bit Hex Dec Alarm Word Warning Word Extended Status Word
0 00000001 1 Brake Check Brake Check Ramping
1 00000002 2 Pwr. Card Temp Pwr. Card Temp AMA Running
2 00000004 4 Ground Fault Ground Fault Start CW/CCW
3 00000008 8 Ctrl.Card Temp Ctrl.Card Temp Slow-down
4 00000010 16 Ctrl. Word TO Ctrl. Word TO Catch Up
5 00000020 32 Overcurrent Overcurrent Feedback High
6 00000040 64 Torque Limit Torque Limit Feedback Low
7 00000080 128 Motor Th Over Motor Th Over Output Current High
8 00000100 256 Motor ETR Over Motor ETR Over Output Current Low
9 00000200 512 Inverter Overld. Inverter Overld. Output Freq High
10 00000400 1024 DC undervolt DC undervolt Output Freq Low
11 00000800 2048 DC overvolt DC overvolt Brake Check OK
12 00001000 4096 Short circuit DC Voltage Low Braking Max
13 00002000 8192 Soft-charge fault DC Voltage High Braking
14 00004000 16384 Line power ph. Loss Line power ph. Loss Out of Speed Range
15 00008000 32768 AMA Not OK No Motor OVC Active
16 00010000 65536 Live Zero Error Live Zero Error
17 00020000 131072 Internal Fault 10 V low
18 00040000 262144 Brake Overload Brake Overload
19 00080000 524288 U phase Loss Brake Resistor
20 00100000 1048576 V phase Loss Brake IGBT
21 00200000 2097152 W phase Loss Speed Limit
Warnings and Alarms Instruction Manual
MG11F522 Danfoss A/S © 08/2014 All rights reserved. 125
8 8
