0 0.0[ ]
176FA279.11
Figure 3.19 IP21 (NEMA Type 1) and IP54 (NEMA Type 12) Enclosure Power Connection Position of Disconnect Switch
Enclosure
size
Unit type Dimensions [mm]/(inch)
E1
IP54/IP21 UL and NEMA1/NEMA12
250/315 kW (350/425 hp) (400 V) and
355/450–500/630 kW (475/600–650/850 hp)
(690 V)
396 (15.6) 267 (10.5) 332 (13.1) 397 (15.6) 528 (20.8) N/A
315/355–400/450 kW (425/475–550/600 hp)
(400 V)
408 (16.1) 246 (9.7) 326 (12.8) 406 (16.0) 419 (16.5) 459 (18.1)
Table 3.5 Dimensions for Disconnect Terminal
Mechanical Installation
VLT
®
HVAC Drive FC 102
20 Danfoss A/S © 08/2014 All rights reserved. MG11F522
