Size/type Bussmann PN* Rating Siba
P500 170M8611 1100 A, 1000 V 20 781 32.1000
P560 170M8611 1100 A, 1000 V 20 781 32.1000
P630 170M6467 1400 A, 700 V 20 681 32.1400
P710 170M6467 1400 A, 700 V 20 681 32.1400
P800 170M8611 1100 A, 1000 V 20 781 32.1000
P1M0 170M6467 1400 A, 700 V 20 681 32.1400
Table 4.14 Enclosure Type F, Inverter Module DC Link Fuses, 380–480 V
*170M fuses from Bussmann shown use the -/80 visual indicator; -TN/80 Type T, -/110 or TN/110 Type T indicator fuses of the same size and
amperage may be substituted for external use.
**Any minimum 500 V UL listed fuse with associated current rating may be used to meet UL requirements.
525–690 V, Enclosure types E and F
Size/type Bussmann PN* Rating Ferraz Siba
P450 170M4017 700 A, 700 V 6.9URD31D08A0700 20 610 32.700
P500 170M4017 700 A, 700 V 6.9URD31D08A0700 20 610 32.700
P560 170M6013 900 A, 700 V 6.9URD33D08A0900 20 630 32.900
P630 170M6013 900 A, 700 V 6.9URD33D08A0900 20 630 32.900
Table 4.15 Enclosure Type E, 525–690 V
Size/type Bussmann PN* Rating Siba
Internal Bussmann
option
P710 170M7081 1600 A, 700 V 20 695 32.1600 170M7082
P800 170M7081 1600 A, 700 V 20 695 32.1600 170M7082
P900 170M7081 1600 A, 700 V 20 695 32.1600 170M7082
P1M0 170M7081 1600 A, 700 V 20 695 32.1600 170M7082
P1M2 170M7082 2000 A, 700 V 20 695 32.2000 170M7082
P1M4 170M7083 2500 A, 700 V 20 695 32.2500 170M7083
Table 4.16 Enclosure Type Size F, Electrical Fuses, 525–690 V
Size/type Bussmann PN* Rating Siba
P710 170M8611 1100 A, 1000 V 20 781 32. 1000
P800 170M8611 1100 A, 1000 V 20 781 32. 1000
P900 170M8611 1100 A, 1000 V 20 781 32. 1000
P1M0 170M8611 1100 A, 1000 V 20 781 32. 1000
P1M2 170M8611 1100 A, 1000 V 20 781 32. 1000
P1M4 170M8611 1100 A, 1000 V 20 781 32.1000
Table 4.17 Enclosure Type F, Inverter Module DC Link Fuses, 525–690 V
*170M fuses from Bussmann shown use the -/80 visual indicator; -TN/80 Type T, -/110 or TN/110 Type T indicator fuses of the same size and
amperage may be substituted for external use.
Suitable for use on a circuit capable of delivering not more than 100,000 rms symmetrical A, 500/600/690 V maximum when
protected by the above fuses.
Supplementary fuses
Enclosure size Bussmann PN* Rating
E and F KTK-4 4 A, 600 V
Table 4.18 SMPS Fuse
