4.
Function Set-ups options appear. Select Q3-1
General Settings. Press [OK].
Q3
130BT113.10
Q3-1 General Settings
Q3-2 Open-loop Settings
Q3-3 Closed-loop Settings
Q3-4 Application Settings
28.4% 2.05A 1(1)
Function Set-ups
Figure 6.5 Function Set-ups Options
5.
Press [
▲
] and [
▼
] to scroll down to Q3-11 Analog
Outputs. Press [OK].
130BT114.10
26.0%
Q3 - 10 Adv. Motor Settings
Q3 - 11 Analog Output
Q3 - 12 Clock Settings
Q3 - 13 Display Settings
7.14A 1(1)
Q3-1
General Settings
Figure 6.6 General Settings Options
6.
Select parameter 6-50 Terminal 42 Output. Press
[OK].
130BT115.10
6 - 50 Terminal 42 Output
(100) Output frequency
26.3% 5.82A 1(1)
Analog Output 03.11
Figure 6.7 Parameter 6-50 Terminal 42 Output Selected
7.
Press [
▲
] and [
▼
] to select between the dierent
options. Press [OK].
130BT116.10
43.4%
6-50 Terminal 42 Output
[107]
Speed
Analog Output
7.99A
Q3-11
1(1)
Figure 6.8 Setting a Parameter
How to Program Instruction Manual
MG11F522 Danfoss A/S © 08/2014 All rights reserved. 83
6 6
