Fuse Size/Type Bussmann PN Rating Alternative fuses
2.5–4.0 A P450–P800, 380–480 V LPJ-6 SP or SPI 6 A, 600 V Any listed Class J Dual
Element, Time Delay, 6 A
P630–P1M2, 525–690 V LPJ-10 SP or SPI 10 A, 600 V Any listed Class J Dual
Element, Time Delay, 10 A
4.0–6.3 A P450–P800, 380–480 V LPJ-10 SP or SPI 10 A, 600 V Any listed Class J Dual
Element, Time Delay, 10 A
P630–P1M2, 525–690 V LPJ-15 SP or SPI 15 A, 600 V Any listed Class J Dual
Element, Time Delay, 15 A
6.3–10 A P450–P800600–1200
hp, 380–480 V
LPJ-15 SP or SPI 15 A, 600 V Any listed Class J Dual
Element, Time Delay, 15 A
P630–P1M2, 525–690 V LPJ-20 SP or SPI 20 A, 600 V Any listed Class J Dual
Element, Time Delay, 20 A
10–16 A P450–P800, 380–480 V LPJ-25 SP or SPI 25 A, 600 V Any listed Class J Dual
Element, Time Delay, 25 A
P630–P1M2, 525–690 V LPJ-20 SP or SPI 20 A, 600 V Any listed Class J Dual
Element, Time Delay, 20 A
Table 10.20 Manual Motor Controller Fuses
Enclosure Bussmann PN Rating Alternative fuses
F LPJ-30 SP or SPI 30 A, 600 V Any listed Class J Dual Element, Time Delay, 30 A
Table 10.21 30 A Protected Terminal Fuse
Enclosure
Bussmann PN Rating Alternative fuses
F LPJ-6 SP or SPI 6 A, 600 V Any listed Class J Dual Element, Time Delay, 6 A
Table 10.22 Control Transformer Fuse
Enclosure
Bussmann PN Rating Alternative fuses
F LP-CC-6 6 A, 600 V Any listed Class CC, 6 A
Table 10.23 Safety Relay Coil Fuse with Pilz Relay
10.5.3 Mains Fuses, F8–F13
The following fuses are suitable for use on a circuit capable of delivering 100000 A
rms
(symmetrical), 240 V, or 480 V, or
600 V depending on the drive voltage rating. With the proper fusing, the drive short-circuit current rating (SCCR) is 100000
A
rms
.
Model Enclosure size Rating Bussmann P/N Spare
Bussmann P/N
Estimated fuse power loss [W]
[V] (UL) [A] 400 V 460 V
P250 F8–F9 700 700 170M4017 176F8591 25 19
P315 F8–F9 700 700 170M4017 176F8591 30 22
P355 F8–F9 700 700 170M4017 176F8591 38 29
P400 F8–F9 700 700 170M4017 176F8591 3500 2800
P450 F10–F11 700 900 170M6013 176F8592 3940 4925
P500 F10–F11 700 900 170M6013 176F8592 2625 2100
P560 F10–F11 700 900 170M6013 176F8592 3940 4925
P630 F10–F11 700 1500 170M6018 176F8592 45 34
P710 F12–F13 700 1500 170M6018 176F9181 60 45
P800 F12–F13 700 1500 170M6018 176F9181 83 63
Table 10.24 Mains Fuses, 380–480 V
